4K clarity lasts for all-day long
The CB8 Pro is an excellent outdoor sentinel with versatile smart features and exceptional durability. With EZVIZ`s unique AOV mode, you can enjoy all-day recording in ultra-clear 4K resolution. It`s guaranteed to keep going all day and you`ll never have to worry about the battery with its large 10,400 mAh rechargeable battery and the ability to use solar power. With its built-in AI chip, it adeptly identifies, detects and follows any approaching human or vehicle while maintaining a 360-degree panoramic view for comprehensive protection.
Specifications
Model CS-CB8-R200-1M8WFL
Camera
Image Sensor 1/2.8`` 8-Megapixel Progressive Scan CMOS Sensor
Minimum Illumination 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
Shutter Speed Self-adaptive shutter
Lens 4mm@ F1.2 Diagonal angle: 104`b0 Horizontal angle: 83`b0 Vertical angle:44`b0
PT Angle Pan: 340`b0, Tilt: 75`b0
Day & Night IR-cut filter with auto switch
DNR 3D DNR
Night Vision 15 m
Video & Audio
Max Resolution 4K (3840 `d7 2160`a3`a9
Frame Rate Max. 15fps; Self-adaptive during network transmission
Video Compression H.265 / H.264
Video Bit Rate Ultra-HD; Quad HD; Full HD; Hi-Def; Adaptive bit rate
Audio Bit Rate Self-adaptive
Max. Bitrate 4 Mbps
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n, 802.11ax
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps, 11ax: 114Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ Cloud Proprietary Protocol
Interface Protocol EZVIZ Cloud Proprietary Protocol
Minimum Network Requirement 8 Mbps
Function
Smart Alarm AI-powered human shape detection AI-powered vehicle shape detection
Two-Way Talk Supports
General Function Anti-Flicker, Heart Beat, Password Protection, Watermark
Storage
Local Storage Supports microSD card (max. 512 GB)
Cloud Storage Supports EZVIZ CloudPlay storage (Subscription required)
General
Operating Conditions -20 `b0C to 50 `b0C (-4 `b0F to 122 `b0F), Humidity 95% or less (non-condensing)
IP Grade IP65
Power Supply DC 5 V / 2 A (Adapter needs to be purchased separately)
Battery Capacity 10,400 mAh
Power Consumption Max.10 W
Product Dimensions 184 `d7 102 `d7 168 mm (7.24 `d7 4.02 `d7 6.61 inch )
Packaging Dimensions 205 `d7 145 `d7 194 mm (8.07 `d7 5.70 `d7 7.64 inch)
Product Weight 780 g (21.51 oz)
Weight with Package 1312 g (46.61 oz)
In the box
In the box - CB8 Pro Camera
- Drilling Template
- Type-C Cable
- Screw Kit
- Quick Installation Guide
- Regulatory Information `d7 3
- Quick Start Guide
Certifications
Certifications CE / REACH / WEEE / RoHS
