Specifications
Model CS-H3-R100-1H3WKFL
General
Dimensions 75.5 `d7 75.5 `d7 155 mm (2.97 `d7 2.97 `d7 6.10 inch)
Package Dimensions 227 `d7 100 `d7 92 mm (8.94 `d7 3.94 `d7 3.62 inch)
Weight Net weight: 438 g (15.45 oz) With package: 676 g (23.84 oz)
IP Grade IP67
Operating Conditions -30 `b0C ~ 60 `baC (-22 `b0F ~ 140 `b0F ) Humidity 95% or less (non-condensing)
Camera
Image Sensor 1/2.7"Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 2.8mm @ F2.0, viewing angle: 122`b0 (Diagonal), 106`b0 (Horizontal), 56`b0 (Vertical) 4mm @ F2.0, viewing angle:102`b0 (Diagonal), 86`b0 (Horizontal), 44`b0 (Vertical)
Minimum Illumination 0.01 lux @ (F2.0, AGC ON), 0 Lux with IR
Lens Mount M12
Day / Night Switch IR-Cut filter with auto-switching
DNR 3D DNR
WDR Digital WDR
BLC Supports
IR Night Vision Distance Up to 98 ft / 30 m
Video & Audio
Max. Resolution 2304 `d7 1296 pixels
Frame Rate Max: 30fps; Self-Adaptive during network transmission
Video Compression H.265 / H.264
Video Bit Rate Quad HD; Full HD; HD; Standard. Adaptive bit rate.
Audio Bit Rate Self-Adaptive
Max. Bitrate 3 Mbps
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Transmission Rate 11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps
Wi-Fi Pairing AP Pairing
Protocol EZVIZ Cloud Proprietary Protocol
Interface Protocol EZVIZ Cloud Proprietary Protocol
Wired Network RJ45 `d7 1 (10M / 100M Adaptive Ethernet Port)
Function
Detection AI-Powered Human / Vehicle Shape Detection, Motion Detection
Customized Alert Area Supports
Integration Works with Alexa, Google Assistant, IFTTT
General Function Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark
Storage
Local Storage Supports microSD card (Up to 512 GB)
Cloud Storage Supports EZVIZ CloudPlay storage (Subscription required)
Power
Wiring Hard-Wired
Power Supply DC 12V / 1A
Power Consumption Max. 7W
In the box
In the box - EZVIZ H3 2K Camera
- Drill Template
- Screw Kit
- Waterproof Kit
- Power Adapter
- Regulatory Information
- Quick Start Quide
Certifications
Certifications CE / FCC / UKCA / UL / WEEE / RoHS / REACH
