Outdoor protection knows no bounds with 4G
The HB8 Lite 4G makes outdoor security simple. When Wi-Fi is weak or unavailable, it automatically switches to 4G to keep you connected without interruption. Designed for flexibility, it offers 24/7 recording with EZVIZ's AOV technology, saving footage directly to a local storage card so you never miss a moment. Pair it with the EZVIZ solar panel for continuous, eco-friendly power. With smart detection and easy setup, it's the worry-free way to protect what matters anytime, anywhere.
Specifications
model
CS-HB8c-R100-1N4WL4GA, CS-HB8c (4MP,W4GA)
Camera
Image Sensor 1/3" 4-Megapixel Progressive Scan CMOS Sensor
Minimum Illumination 0.01 Lux @(F1.6, AGC ON), 0 Lux with IR
Shutter Speed Self-adaptive shutter
Lens 4mm@ F1.6 Diagonal angle: 90`b0 Horizontal angle: 75`b0 Vertical angle:40`b0
PT Angle Pan: 340`b0, Tilt: 80`b0
Day & Night IR-cut filter with auto switch
DNR 3D DNR
Night Vision 15 m
Video & Audio
Max Resolution 2K+ (2560 `d7 1440)
Frame Rate 15fps; Self-adaptive during network transmission
Video Compression H.265 / H.264
Video Bit Rate Ultra-HD; Full HD; Hi-Def; Adaptive bit rate
Audio Bit Rate Self-adaptive
Max. Bitrate 4 Mbps
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n, 802.11 ax
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps,11g :54Mbps,11n :72Mbps, 11ax:114Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ Cloud Proprietary Protocol
Interface Protocol EZVIZ Cloud Proprietary Protocol
Minimum Network Requirement 4 Mbps
Frequency Bands IN LTE-FDD: B1/B3/B5/B8 IN LTE-TDD: B34/B38/B39/B40/B41 EU LTE-FDD: B1/B3/B5/B7/B8/B20/B28 EU LTE-TDD: B38/B40/B41 LA LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66 LA LTE-TDD: B38/B40/B41
Function
Smart Alarm AI-powered human shape detection AI-powered vehicle shape detection
Two-Way Talk Supports
General Function Anti-Flicker, Heart Beat, Password Protection, Watermark
Storage
Local Storage Supports microSD card (max. 512 GB)
Cloud Storage Supports EZVIZ CloudPlay storage (Subscription required)
General
Operating Conditions -20 `b0C to 50 `b0C (-4 `b0F to 122 `b0F), Humidity 95% or less (non-condensing)
IP Grade IP65
Power Supply DC 5 V / 2 A (Adapter needs to be purchased separately)
Battery Capacity 5,200 mAh
Power Consumption Max.10 W
Product Dimensions 168 `d7 100 `d7 137.2 mm (6.61 `d7 3.94 `d7 5.40 inch)
Packaging Dimensions 205 `d7 145 `d7 194 mm (8.07 `d7 5.70 `d7 7.64 inch)
Product Weight 660 g (23.28 oz)
Weight with Package 1120 g (39.50 oz)
In the box
In the box - HB8 Lite 4G Camera
- Drill Template
- Screw Kit
- Power Cable
- Regulatory Information `d7 2
- Quick Start Guide `d7 2
Certifications
Certifications CE / REACH / WEEE / RoHS
