Fanvil CP20 4K Wireless Screen-Sharing Pod for Fanvil CA200/CA400

Share, Freeze and Control Content with One Touch.

The Fanvil CP20 is a compact 4K wireless screen-sharing pod designed for the Fanvil CA200 and CA400 conferencing systems. Connect it to a compatible full-featured USB Type-C port to share content at up to 3840 × 2160 @30fps without installing drivers or software. Dedicated buttons provide one-touch screen sharing, screen freezing and synchronised volume control. The CP20 can also provide wireless access to compatible UVC cameras, microphones and speakers through the connected conferencing system. Up to four CP20 transmitters can be paired for seamless switching between presenters, while Wi-Fi 5 and Wi-Fi 6 connectivity, WPA3-PSK encryption and a transmission range of up to 10m support secure and flexible meeting-room collaboration.

FEATURES

4K Wireless Screen Sharing - Shares content at resolutions up to 3840 × 2160 @30fps
One-Touch Operation - Starts or ends screen sharing with a single button press
Screen Freeze Control - Pauses and resumes shared content without disconnecting
Multi-Presenter Support - Supports up to four paired CP20 transmitters for seamless switching
Plug-and-Play - Requires no additional drivers or screen-sharing software
Wireless AV Access - Provides access to compatible UVC cameras, microphones and speakers
Synchronous Volume Control - Adjusts the connected conferencing system's audio level directly from the pod
Mirror and Extended Modes - Supports compatible mirrored and extended desktop configurations
Low-Latency Transmission - Provides an average screen-sharing latency of approximately 150ms
WPA3-PSK Security - Protects wireless screen-sharing data with modern encryption
Wi-Fi 5 and Wi-Fi 6 - Supports stable 5.0GHz wireless transmission
10m Wireless Range - Provides flexible presenter movement within compatible meeting spaces
Compact USB Type-C Design - Connects directly to compatible laptops, tablets and smartphones
CA200 And CA400 Integration - Designed for seamless operation with Fanvil wireless conferencing solutions

SPECIFICATIONS

Compatible Systems: Fanvil CA200 And CA400
Maximum Screen Output Resolution: 3840 × 2160 @30fps
Average Latency: Approximately 150ms
Desktop Modes: Mirror and Extended
Maximum Simultaneous Transmitters: up to 4
Wireless Standards: Wi-Fi 5 and Wi-Fi 6
Wireless Frequency Band: 5.0GHz
Wireless Security: WPA3-PSK
Transmission Distance: up to 10m
Host Interface: USB Type-C with Power Delivery and DisplayPort Alternate Mode
USB Cable Length: 85mm
Operating Voltage: 5V
Power Consumption: 2.5W
Buttons: Screen Sharing, Screen Freeze, Volume Up and Volume Down
LED Indicators: Red and Green
Freeze Indicator: Green for Resume, Red for Pause
UVC and UAC Access: Supported with Compatible Equipment
Supported Operating Systems: Windows 10, Windows 11 and macOS 10.8 or Later
Compatible Host Devices: PCs, Laptops, Tablets and Smartphones with Full-Featured USB Type-C
Dimensions: 189 × 40 × 18mm
Weight: 62g
Operating Temperature: -10~40°C
Operating Humidity: 0~90% RH
Certifications and Compliance: CE, FCC and RoHS

NOTES

A full-featured USB Type-C port supporting DisplayPort Alternate Mode is required for direct connection
Wireless camera and audio access require the Fanvil RC10 receiver hub within a compatible CA200 or CA400 system
Voice and video functions require compatible UAC and UVC equipment
