Panel characteristics:
1. Screen size: 4.5 inches
2. Resolution: 200x800 pixels
3. Dot pitch: 0.07575 (H)x0.02525 (W) mm
4. Screen ratio: 16:10
5. Brightness: 470cd/square meter
6. Contrast ratio: 900:1
7. Backlight source: LED
8. Viewing angle: 80 degrees/80 degrees (L/R) 80 degrees/80 degrees (U/D)
Enter:
1. 1x HDMI: HDMI
2. 1x VIDEO: VIDEO
Output:
1. 1x HDMI: HDMI
Audio:
1. Audio: headphone jack
HDMI support format:
480i/576i/480p/576p
720p (60/59.94/50/30/29/25/24/23.98)
1080i (60/59.94/50)
1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)
4K UHD 3840x2160p (30/29.97/25/24/23.98Hz), 4096x2160p (24Hz)
Other specifications:
1. Input voltage: DC7-18V
2. Power consumption: greater than or equal to 5W
3. Working temperature: -20-50 degrees Celsius
4. Storage temperature: -30-65 degrees Celsius
5. Installation method: 1/4 inch-20 standard quick installation screw hole
6. Stand-alone size: 126Lx72Hx16D mm
7. Stand-alone weight: 170g/ 200g (including F970 battery gusset)
Product Features
1. Wide-angle screen, high-definition LCD display, rich color levels
2. 4K HDMI input and loop out
3. Product features:
-Peaking assist focus (red border on black and white background)
-Monochrome display (red, green, blue, monochrome)
-5D II camera mode
-peer to peer
-Center mark
-Box mark (percent 80, percent 85, percent 90, percent 93, percent 96, 2.35:1)
-Image flip (horizontal, vertical, horizontal & vertical)
-Image freeze
-Color temperature adjustment
4. 3.5mm headphone jack
5. Material: aluminum-magnesium alloy
6. The monitor comes with rich functions, which is very suitable for high-end broadcast monitoring work, such as auxiliary focus, monochrome display, camera mode, center mark, frame mark, image freeze, image flip, image display ratio switching, color temperature Adjustments, etc., can help the photographer to better focus and frame the view, and obtain clearer and high-quality images more quickly.
7. It has perfect functions and lightweight design. The 18mm ultra-thin body, the whole machine is as light as 120g, so you can easily hold it in your palm for monitoring. It can also be used with a handheld stabilizer. It is a powerful tool for shooting with a handheld stabilizer.
8. When shooting weddings, independent films, and TV commercials, no matter what type of camera you are using, you need to make sure that the shots are in focus and captured with the highest quality. The FEELWORLD FW450 can ensure that every lens shot is accurately focused, allowing you to obtain professional-grade exquisite picture quality comparable to large-scale film and television productions and prime-time TV programs.
9. While having a thin and light design, it can still maintain extraordinary picture quality. Its 4.5-inch high-brightness LCD display has a full HD 1280x800 resolution, coupled with a 900:1 high contrast ratio, the display quality is more delicate and lifelike, and it can bring you a real and natural visual experience when shooting on-site! In addition, the 160-degree wide viewing angle of the display screen can also provide a clear picture view for multiple crew members at the same time.
Shipping list:
1. Mini HDMI cable x1
2. Sun visor x1
3. Small head x1
4. F970 battery gusset x1
5. 1/4 lock x1
6. Manual x1
