TCP / IP
Fluke has substantially enhanced support for today?s growing TCP/ IP networks. TCP/IP has rapidly become the most important network protocol for many enterprise- wide networks. The Enterprise LANMeter provides features designed to show key IP network configuration information that is necessary to troubleshoot connectivity and configuration problems in IP networks. In addition, Enterprise LANMeter can use SNMP commands to retrieve configuration and status information, such as route table and bridge forward table, to further facilitate quick diagnostic of network problems in switched or routed environment.
SNMP
The Enterprise LANMeter is the first portable tool to include SNMP-based troubleshooting capabilities, in an easy-to-use format to reach beyond the attached LAN segment. The unique capability to query via SNMP (including MIB I, II and RMON queries) allows access to information that already exists in managed devices throughout the entire network.
Support You Can Count On The LANMeter analyzer?s Flash ROM Technology protects your investment by allowing quick and easy software updates from your PC. If anything should go wrong, you can count on Fluke?s worldwide service and support to get you up and running fast.
Cable Identifier
Used to map UTP drop and lobe cables to individual offices from the wiring closet. Unique Cable Identifier Remote Units are identified and displayed in the order detected. Up to thirteen identifiers can be connected.
Ethernet
HUB Autotest Tests new or suspected faulty hub and switch ports for correct operation by testing for the presence and polarity of link pulses, offered auto negotiation capabilities and for hub transmit levels. Protocols detected are identified, and selected local IP hosts and IPX servers are queried to ensure connectivity. Cable tests are performed when a cable fault is suspected.
SwitchWizard Option
This option shows what is occurring at each port of a multiinterface device. This test displays utilization and error percentages for up to eight ports simultaneously, while monitoring the other ports in the background. The user may sort the data by port number, average utilization or average error rates. The SwitchWizard Option will display information for any type of SNMP monitored port: Ethernet, Token Ring, Serial Links, FDDI, even very high speed switch backplanes. SwitchWizard will provide detailed Interface Statistics on the selected port, including utilization, error rates, and broadcast levels. You can obtain greater detail on the specific types of errors by pressing the Interface Errors softkey.
WideAreaWizard Option
This option allows access to information from WAN interfaces selected from the Internet Toolkit, Interface Table test.
WebRemote Control Option
Optional advanced features The WebRemote Control option expands the standard web server function of the Enterprise
LANMeter to allow full remote control of all test functions through a web browser. Users can access the power of the Enterprise LANMeter regardless of where they are. The access is password protected to prevent unauthorized access to the Enterprise LANMeter. Imagine that you can dispatch the Enterprise LANMeter to a remote site and remotely control it to troubleshoot the network without leaving your office. In addition, datalog sessions can be initiated remotely to create a network baseline report for network segments.
Features available through virtually any web browser include:
Navigate the LANMeter menus and screens
View the current Enterprise LANMeter display
Retrieve test results
Retrieve screen captures
Retrieve station lists
Retrieve data logs
