AMD Phenom™II,Athlon™II processor, Socket AM3
AMD® 690G + SB600
Front Side Bus 2000 MT/s HyperTransport™
Memory Dual channel DDR3 1333/1066 x 2 DIMMs, Max 8GB
VGA on Die Integrated ATI®Radeon™ 1250 graphics
Expansion Slots 1 PCIe x16, 1 PCIe x1, 2 PCI
IDE 1 ATA133
Serial ATA(SATA)/RAID 4 Serial ATA II w / RAID 0, 1, 0+1 JBOD
5.1 channel HD audio
Gigabit LAN
Back Panel I/O Ports 1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x VGA port
1 x Serial port
1 x Audio jack supports 3 jacks
4 x USB 2.0 ports
1 x RJ45 LAN port
1 x Parallel port
Internal I/O Connectors 1 x ATX 24-Pin power connector
1 x 4-pin ATX 12V power connector
2 x 4-pin CPU / System FAN connectors
1 x ATA133 IDE connector
1 x Front Audio header
1 x Front Panel header
2 x USB 2.0 headers support additional 4 ports
4 x Serial ATAII connectors
1 x Intrusion Alarm header
1 x CD-in connector
1 x S/PDIF out header
1 x Speaker
BIOS Features 8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI 2.0
Support CD WHQL Drivers, Adobe Reader 7.07, Direct x 10.0, Norton 2006
Standards/Manageability PCI 2.3, USB2.0, DMI 2.5
Special Features
Micro ATX (9.6" x 8.4")
