FSP Hydro PTM Pro 1200W ATX3.0 PCIe Fully Modular 80 PLUS Platinum Power Supply Unit

FSP Hydro PTM Pro 1200W ATX3.0 PCIe Fully Modular 80 PLUS Platinum Power Supply Unit PPA12A1020

The Hydro PTM PRO 1200W ATX Fully Modular Power Supply has a fully modular design with all-black coated ribbon cables for a more aesthetically pleasing solution. The HYDRO PTM Pro series includes an FDB fan and an intelligent 0dBA function to reduce noise and provide longer life. Furthermore, the fan has a longer lifespan than a regular fan. Hydro PTM Pro series power supplies have 80 Plus Platinum Certification, which implies they consume less heat and have a reduced running cost. At 50% load, the power supplies are guaranteed to perform at a minimum efficiency of 92%.

The series includes a native PCIe5.0 connector as well as 4 x PCIe 6+2Pin slots for graphics cards and 2 x CPU connector slots for increased performance. The HYDRO PTM Pro series has highly tight voltage regulation, with output voltage regulation of less than +/- 1% above 10% load change and superior efficiency and voltage stability. When the Eco Button is turned on, the PSU consumes less power and runs quietly. When the power supply is under 30% load, the fan in the power supply will not run, resulting in a silent state.

FEATURES:

• Complies with ATX12V V3.0 & EPS12V V2.92
• Intel's Latest CPU ready
• Global Safety Approved
• High efficiency ⧠92%
• Powerful +12V single rail design
• Quiet and durable cooling
• Full Japanese electrolytic capacitors
• Intelligent fan speed control circuit design
• Full protections OCP, OVP, SCP, OPP, OTP, UVP
• High Wattages with 80PLUS® Platinum Certification
• Unique product ID with changeable side stickers for DIY enthusiasts and gamers

SPECIFICATIONS:

• Rated Output Power: 1200W
• Form Factor: ATX
• 80 PLUS Certification: 80 PLUS Platinum
• Input Voltage: 100-240V
• Input Current: 14-9A
• Input Frequency: 50-60Hz
• PFC: Active PFC
• Efficiency: 92%
• Fan Type: FBD Fan, 13.5 cm
• Protection: OCP, OVP, OPP, SCP
• Cable Connections:
• ATX 20+4 x 1
• 4+4 PIN x 3
• 12VHPWR x 1
• PCI-E 6+2 x 6
• SATA x 14
• Molex (PERIPHERAL) x 5
• Floppy x 1
• Dimensions: 15 x 19 x 8.6 cm

WHAT'S IN THE BOX:

• FSP Hydro PTM Pro 1200W ATX Fully-Modular Power Supply Black x1
