Features
Customizable status LED bar with RGB lights
Touchable button with large 5" colored LCD
Built-in Wi-Fi for mobile monitoring (Android/iOS App is available)
Supports USB On-the-Go function
Data log events stored in the inverter
Reserved communication port for BMS (RS485, CAN-BUS, or RS232)
Replaceable fan design for ease of maintenance
Battery independent design
Configurable AC/PV output usage timer and prioritization
Selectable high-power charging current
Compatible with Utility Mains or generator input
Built-in anti-dust kit
Built-in DC output for DC fan, LED bulb, router, and so on
Parallel operation with 6 units
Specifications
Rated Power: 11000VA / 11000W
Parallel Capability: YES, 6 units
INPUT
Voltage: 230 VAC
Selectable Voltage Range: 170-280 VAC (For Personal Computers), 90-280 VAC (For Home Appliances)
Frequency Range: 50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode): 230 VAC ± 5%
Surge Power: 22000VA
Efficiency (Peak): 93%
Transfer Time: 15 ms (For Personal Computers), 20 ms (For Home Appliances)
Waveform: Pure sine wave
No Load Power Consumption: < 70W
DC Voltage: 12 VDC ± 5%, 100W
BATTERY
Battery Voltage: 48 VDC
Floating Charge Voltage: 54 VDC
Overcharge Protection: 63 VDC
SOLAR CHARGER & AC CHARGER
Solar Charger Type: MPPT
Maximum PV Array Power: 11000W (5500W x 2)
MPPT Range @ Operating Voltage: 90 ~ 450 VDC
Maximum PV Array Open Circuit Voltage: 500 VDC
Maxmum Solar Charge Current: 150A
Maximum AC Charge Current: 150A
Maximum Charge Current: 150A
PHYSICAL
Dimension, D x W x H (mm): 158.4 x 502.5 x 530.8
Net Weight (kgs): 20
Communication Interface: USB/RS232/RS485/WiFi/Dry-contact
