Generator

Characteristics:
1.The efficient combustion assured by
Jetman's
OHV 4-stroke engine technology
delivers solid,
dependable power while consuming
nearly 30% less fuel than the
comparable
side-valve engines.
2.It’s capable of supplying nearly 12
hours of
continuous operation without refueling.
3.Electric starter.
4.Oil Alert system protects engine by
stopping
it automatically if the oil level drops
below
the standard level
5.High-performance of special new oil
bath air
filter is ideal for work at dusty work site
Alternator:

Specifications:

• AC Frequency (Hz)  50Hz

• AC Output voltage(V)  220;230;
  240;115/230

• Rated AC Output  5.0kW

• Max.AC Output  6.0kW

• Power Factor  1.0

• DC Output  12V/8.3A

• Engine  UP188

• Type  OHV 4-Stroke; Air-cooled;
  Single-Cylinder

• Displacement(cc)  389

• Starting System  Recoil/Electric

• Lubrication oil  SAE 10W/30

• Max.Output(hp/rpm)  13.0/3000

• Fuel Tank Capacity(l)  25

• Continuous Work(h)  10

• Noise Level LwA dB(A)  96

• Dim(mm)  697X525X562

• Gross Weight(kg)
