The Giada D613, armed with an Intel Raptor Lake Core i3-1315U processor, introduces a new era of performance and efficiency. The processors feature a combination of high-performance and efficient cores, working in harmony to optimise power consumption without compromising processing power. With support for 4 simultaneous 4K60 displays and hardware-accelerated video encoding and decoding, Giada D613 delivers stunning visuals and an immersive multimedia experience. Intel® Hardware Shield delivers integrated hardware-based PC protection, which includes below-the-OS security, application and data protection, and advanced threat detection. 5G provides game-changing benefits like speeds up to 10 times faster than 4G LTE speeds, a safer alternative to public Wi-Fi, low latency, and massive capacity. The Quectel®-RM50XQ 5G module was certified to be compatible with D613.
FEATURES:
Intel® Core i3-1315U processor
4 x HDMI, Supporting 4K Display
2 x SO-DIMM DDR4 Memory, Up to 64GB
1 x M-key M.2 (2242/2280) for SSD
Supporting RJ45, Wi-Fi 6 (CNVi), and 3G/4G/5G Ethernet Access
SPECIFICATIONS:
Processor:
CPU: Intel® Core i3-1315U processor
Frequency: 3.30GHz (Up to 4.50GHz )
Cores: 6
BIOS: AMI EFI 64 Mbit
Memory:
Type: DDR4-3200MHz
Socket: 2 x SO-DIMM
Max Size: 64GB
Graphics:
GPU: Intel® UHD Graphics
Graphic Engine: DirectX 12.1, OpenGL 4.6, OpenCL 3.0, 8K 60fps 12b 4:2:0 HEVC/VP9/SCC
HDMI: 4 x HDMI (Max.4096 x 2304 @60 Hz)
Network:
Controller: 1 x Intel® i219LM Gigabit Ethernet
Interface: 1 x RJ45
Mobile Network: 1 x B-Key M.2 (3042/3052) for 3G/4G/5G, 1 x SIM Slot
Wi-Fi/BT: 1 x E-Key M.2 (2230) for Wi-Fi/BT, Support Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E (CNVi)
I/O:
USB: 1 x USB3.2 Gen2, 2 x USB2.0
USB Type-C: 1 x USB Type-C3.2 Gen2
Serial Port: 1 x RS232
Audio: 1 x 2-in-1 Headset (MIC-IN & AUDIO-OUT)
Button: 1 x Power on, 1 x CLR-CMOS
Storage:
M.2: 1 x M-key M.2 (2242/2280) for NVMe
JAHC Tech:
WatchDog Timer: 0~255 Second Time Out Support
Auto Power On: Power Activated Automatically Start
Operation System:
Windows: Windows 11 (64bit)
Linux: Linux Ubuntu (64bit)
Chrome: Chrome OS
Power:
Power Type: DC-IN
Input Voltage: 19 V/4.74 A
Environment:
Operating Temperature: 0 ~ 40 ( 32 ~ 104 ) at 0.7m/s Air Flow
Relative Humidity: 95%@40 (non-condensing)
Certification: CE, FCC Class B, CCC
Mounting: Desk/Wall Mounting and VESA Mounting Kit (JZ183)
Construction: Metal
Colour: Black
Dimensions: 18.9 x 14.8 x 2.6 cm
WHAT'S IN THE BOX:
Giada D613 Intel Core i3 High-end Digital Signage Player Black x1
Wi-Fi Antenna x2
User Manual x1
