The Giada DN74 ARM Fanless Android Signage Player utilises an RK3399 Dual-core ARM Cortex-A72 and a Quad-core ARM Cortex-A53 CPU. It has onboard memory and eMMC storage. Its dual HDMI outputs support two displays, with one reaching 4K resolutions and the other running at a resolution of 2K. Giada brings all of these components together with the Android 7.1 operation system, making it a suitable entry-level signage player for Android environments.
Features:
Rockchip RK3399
Onboard 4GB LPDDR4 memory
Two HDMI ports, one supporting 4K and the other 2K
Onboard eMMC storage of 32GB
One USB3.0 port and three USB2.0 ports
RS232 Serial Port
RJ45 Network connection
Mini-PCIe slot for 3G/4G connectivity
SIM Card slot
Specifications:
Processor
CPU: Rockchip RK3399
Frequency: Up to 1.8GHz
Processing Units: 2 Cores Cortex-A72 & 4 Cores Cortex-A53
TDP: 6W
Memory
Type: LPDDR4
Socket: Onboard
Size: 4GB
Graphics
GPU: Mali-T860MP4
Graphic Engine: OpenGL ES1.1/2.0/3.0/3.1, OpenCL, Support AFBC (ARM Frame Buffer Compression)
Video Decoding Capability: 4K VP9 decoders, 4K 10bits H.265 video decoders, 1080P VC-1, MPEG-1/2/4, VP8 video decoders
Display
HDMI: 1x HDMI (Max. 4K@60Hz) | 1x HDMI (Max. 2K@30Hz)
Network
Controller: 1 x Pef7071 PHY
Interface: 1x RJ45
I/O
USB: 1 x USB3.2 Gen1 (OTG), 3 x USB2.0
Serial Port: 2x RS232
Audio: 1x MIC-IN, 1x AUDIO-OUT
Mini-PCIe: 1x Full-size Mini-PCIe for 3G/4G
SIM: 1x SIM Slot
WiFi on Board: 1x WiFi Module Onboard (WIFI 5GHz, IEEE802.11 a/b/g/ac)
Storage
eMMC: 32GB
Power
Power Type: DC-IN
Power Adapter: 12V/2A
Environment
Operating Temperature: 0 ~ 40 at 0.7m/s Air Flow
Relative Humidity: 95%@40 (non-condensing)
Supported Operating Systems: Android 7.1
Mounting: Desk/Wall Mounting and VESA
Certification: CE, FCC
Dimensions: 11.66 x 10.74 x 3 cm
What's in The Box:
Giada DN74 ARM RK3399 Fanless Android Signage Player 32GB x1
AC Power Adapter x1
WiFi Antenna x1
