Giada F108D Intel N100 1xDDR4 3200 Mhz 2xHDMI

The Giada F108D Signage Player adopts Intel® Alder Lake-N processors, giving yougood performance while featuring a low-power range from 6-15W. The book-sizeembedded PC is specially designed for digital signage and kioskapplications. The slim embedded PC supports rich I/O ports, including dual COMports, 6 USB Type-A and dual LAN ports. It can also be easily integrated intovending machines, self-service and check-in kiosks. The digital signage playeralso comes with built-in Intel® UHD Graphics. It has a DP and two HDMI ports,supporting resolutions up to 4096 x 2160@60Hz. With a passive thermal coolingsystem, the fanless design reduces the failure rate and makes the device runnoise-free and dustproof.FEATURES: * Intel® Processor N100 * DDR4 3200MHz memory support * Intel UHD onboard graphics * Up to 4k resolution support * 1x DP and 2x HDMI output * Support for Wi-Fi/Bluetooth module * Small form factor designSPECIFICATION: * CPU: Intel® Processor N100 (Fanless) * Turbo Frequency: 3.40GHz * Chipset: SoC * Processing Units: 4 Cores * TDP: 6W * System Memory: Up to 16 GB, 1 x SO-DIMM DDR4-3200 MHz * Storage: 1 x M-Key M.2 (2280) for PCIe3.0 X4 SSD * Watchdog Timer: Yes * Auto Power On: Yes * RTC: Set up independently every day, a week as a cycle * Remo on: No * Power Requirement: DC-IN, 19 V/2.37 A * Construction: Metal * Operating System: Windows 11 (64bit) /Linux Ubuntu (64bit) * Operating Temperature: 0°C ~45°C (32°F~113°F) @0.7m/s Air Flow * Certifications: CE, FCC Class B, UKCA * Humidity: 95% @ 45°C (non-condensing * Network Controller: 2 x Realtek RTL 8111H Gigabit Ethernet * Ethernet Interface: 2 x RJ45 * Wi-Fi/BT: 1 x E-Key M.2 (2230) for Wi-Fi/BT, Support Wi-Fi 5, Wi-Fi 6 * Mobile Network: 1 x B-Key M.2 (3042) for 3G/4G, 1 x SIM Slot * GPU: Intel® UHD Graphics * Graphic Engine: DirectX 12.1, OpenGL 4.6, OpenCL 3.0 * Display Interface: 1 x DP (Max.4096 x 2160 @60Hz), 2 x HDMI (Max.4096 x 2160 @60Hz) * USB: 2 x USB3.2 Gen2, 4 x USB2.0 * Serial Port: 2 x RS232 * Audio: 1 x MIC-IN, 1 x AUDIO-OUT * Button: 1 x Power on, 1 x CLR-CMOS * Antenna: 2 x Connector for Wi-Fi/BT * Product Dimensions: 18.9 x 14.8 x 2.6 cmWHAT'S IN THE BOX: * Giada F108D Alder Lake-N Book Size Signage Player - Black x1
