** GIGABYTE GA-H67A - UD3H ** GAMING MOTHERBOARD **


** GOOD CONDITION **
** WARRANTY **
** 3D PRINTED IO SHIELD, THAT YOU WOULD NEED TO CUT OUT YOURSELF **

PRODUCT SPECIFICATIONS:

CPU Socket: LGA 1155

Chipset: Intel H67

Processor Support: Intel Core i7/i5/i3, Pentium, and Celeron (2nd Generation)

Memory: 4x 240-pin DDR3 DIMM slots, Dual Channel architecture, up to 32GB, supporting DDR3 1333/1066/800 MHz modules

Storage:

2 x SATA 6Gb/s connectors

3 x SATA 3Gb/s connectors

1 x eSATA 3Gb/s connector

RAID 0, 1, 5, 10 support

Expansion Slots:

1 x PCI Express x16 slot (running at x16)

1 x PCI Express x16 slot (running at x4)

2 x PCI Express x1 slots

3 x PCI slots

Onboard Video: Integrated graphics supported by CPU, with output ports including HDMI, DisplayPort, and DVI-D

Audio: Realtek ALC889 codec, 8-channel High Definition Audio, with optical S/PDIF out

LAN: Realtek RTL8111E chip, 10/100/1000 Mbit (Gigabit Ethernet)

Rear Panel Ports: 2x USB 3.0, 4x USB 2.0, HDMI, DisplayPort, DVI-D, eSATA, Optical S/PDIF, PS/2 Keyboard/Mouse Combo, 6x Audio Ports

Form Factor: ATX
