Goobay 60Hz HDMI Audio Extractor

Extracts the audio signals from an HDMI™ source device and transmits them to a terminal device

Use an audio extractor to provide crystal-clear sound transmission - perfect for connecting home entertainment or gaming systems with HDMI™ to digital and analogue hi-fi systems or sound bars. The HDMI™ output simultaneously transmits high-resolution video signals to projectors or TV sets. Thanks to its compact format, the converter can be discreetly integrated into your living room landscape.

Features:

• HDMI converter sends the best digital and analogue sound quality to devices without their own -HDMI connection, e.g. headphones, hi-fi system, soundbar or TV
• Extractor converts the incoming digital HDMI audio signal into an analogue stereo signal for connected terminals
• Via the HDMI output, the HDMI audio splitter achieves a video resolution of max. 4K2K - 60 Hz and also supports 3D
• Plug & Play facilitates connecting the S/PDIF splitter without installing additional drivers.
• Sturdy aluminium housing dissipates heat
• Equipped with gold-plated connections for corrosion protection and high-quality signal transmission

Specifications:

• Labelling: The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Connections:

• Connection, type: HDMI™ female (Type A)
• Connection 2, type: Toslink male
• Connection 3, type: Jack 3.5 mm socket (3-pin, stereo)

Device connections:

• Input, type: HDMI™ female (Type A)
• Output 2, type: Toslink male
• Output, type: HDMI™ female (Type A)
• Output 3, type: 3.5 mm female (3-pin, stereo)

Signal transmission:

• max. transmission rate: 18 Gbit/s, 4K Ultra HD 2160p (60 Hz)
• other supported standards: HDCP 2.2, HDCP 1.4
• Supported video standards: 4K Ultra HD 2160p (60 Hz), 4K Ultra HD 2160p (30 Hz), Full HD 1080p (60 Hz), Full HD 1080i (60 Hz), 3D
• supported audio standards: Dolby Atmos, Dolby Digital HD (DTS HD), Dolby Digital TrueHD, Dolby Digital 5.1 (AC-3), Dolby 5.1, Dolby 7.1, LPCM, Stereo, Enhanced Audio Return Channel (eARC), Audio Return Channel (ARC)

General:

• Color: black
• Operating temperature from: 0 °C
• Operating temperature up to: 40 °C
• Packaging type: Bulk
• Dimensions / Weight
• Length: 68.5 mm
• Width: 60.5 mm
• Height: 20 mm
• Weight: 97 g
• Consumption Unit: 1 pc. in cardboard box
