GPS Watch Deluxe (Location Finder + Data Logger + Photo Tagger) - ELHN-TR13
A marvelous GPS device combined with a high quality watch containing precision Seiko quartz movement. The benefit to you is advanced GPS features and a truly beautiful timepiece. Just google how much a Seiko watch costs and you'll recognize this opportunity of a lifetime: To own an amazing Seiko movement wristwatch with GPS functionality. Bravo!
Locate places at just the touch of a button: With multiple directional LED's, this watch will intelligently direct you back to a previously logged (POI) point of interest (like where you parked your car or your hotel). When you come within 50 meters of the saved location, the arrows around the watch face will begin flashing, and when you are within 15 meters the arrows will turn blue, letting you easily and conveniently find your destination!
Record GPS data of your trip: With the built-in data logger, this GPS watch will constantly record your position, speed, and altitude, so when you get home, connect the GPS watch to your computer and use the included iTravel Data Logger software package to view all your logged paths right on Google Maps or Google Earth. This powerful, easy-to-use function lets you relive every point along your trip, as well as share with others!
Photo tagger: Use the included Photo Tagger software to show locations where you have taken photos and share your memories with others. Now your family and friends all over the world can see your pictures and the exact location where you took them!
At a Glance...
Photo Tagger
Location Finder (POI)
Ultra portable GPS unit embedded in watch
Data Logger (Records location, speed and altitude)
View your paths on Google Maps or Google Earth
Manufacturer Specifications
Primary Function: Four-in-one GPS location finder, receiver, data logger, photo tagger, plus analog watch for telling time
8 LED's indicate direction clearly
Able to record point of interest (POI)
Switch between Location Finder and Data Logger modes
Chipset: Skytraq Venus 6
Frequency: L1,1575.42 MHz
C/A Code: 1.023MHz
Channels: 65-Channel all-in-view tracking
Tracking Sensitivity: -160 dBm
Re-acquisition: -157 dBm
Accuracy
- Horizontal Position: 10m 2D RMS (without SA)
- WAAS, Egnos supported: 5m 2D RMS(without SA)
- Time: 1 micro-second synchronized to GPS time
- Velocity: 0.1m/sec 95% (without SA)
Datum: WGS-84
Acquisition Rate
- Hot Start: 1 sec.
- Warm Start: 25 sec.
- Cold Start: 29 sec.
- Reacquisition: GPS Output data: NMEA-0183 V3.01; SkyTraq Binary
Operation Range:
- Max Acceleration: Up to 4G
- Max Altitude: Up to 18,000 meters
- Max Velocity: Up to 515 meters/sec.
Output Data Format: WGS 84
Log Interval: By time (1 sec. to 30 mins) or distance (1 to 65,535 meters)
Memory: Store up to 100,000 records in flash memory (8M bits)
Dimensions: Diameter:45 x H:18 (mm)
Log Data: Longitude, Latitude, Speed, Altitude, UTC
USB: Mini-USB port and cable included (for GPS receiver mode and recharging)
Power: Internal 800MAh lithium rechargeable battery
Battery Life: 21 hours usage
Temperature:
- Operating: -20 to +60 degrees Celsius
- Storage: -20 to +80 degrees Celsius
- Humidity: Up to 95% non-condensing
Interface: USB port
Dimensions: Face - Diameter:45 x Hight:19 (mm)
Dimensions: Strap - Diameter:70 (mm), one size fits all.
Certifications: CE, FCC, RoHS, ISO9001
Software Functions
View in Google Maps or Google Earth
Upload photos to Flickr and Flickr Maps.
View multiple paths simultaneously.
Adjust color and width of tracks.
Display speed and altitude graphed against time.
View speed, altitude, and GPS coordinates at any point on your path.
Add photos, videos, audio files, comments, and place names to any point on your track.
Write GPS info into photos.
View slide show of your photos.
Shift photo date and time
Easy track editing.
Display distance in metric or imperial units.
Display GPS coordinates in Degrees or Degrees, Minutes, Seconds
Detects GPS devices quickly and automatically
Configure GPS device to log by intervals of time (every 5 sec., every 10 sec., etc.), distance (every 5 meters, 10 meters, etc.) or speed (over 8 km/hr, over 25 km/hr, etc.). Can be configured to log when one condition is met (e.g. create a log every 3 seconds) or only when multiple conditions are met (e.g. create a log every 10 meters when speed is greater than 60 km/hr).
Export your paths as .KML, .NMEA, .GPX, or .CSV files to share your trips with your family and friends.
No fees/subscriptions: Included software is free and requires no subscription for any of the above functions.
Languages: English, Spanish, French, German, Dutch, Italian, Portuguese, Russian, Thai, Czech, Japanese, Simplified Chinese, Traditional Chinese.
Compatibility: Windows 2000, XP, Vista, 7 (32 bit versions only)
Product Notes
GPS data logger and photo tagger functions require only this device and the free included software: no subscriptions, no fees!
Accurate within up 15 meters
Low power consumption
Quick reacquisition of satellites
NOTE: When using this watch as a plug-in GPS receiver for your computer, the GPS watch is compatible with most brands of GPS software maps, however we provide the GPS-enabled hardware only, not the software.
Package Contents
GPS Watch Deluxe- Location Finder, Data Logger, Photo Tagger, Receiver
CD with Software
User Manual - English
USB Cable
Power Adapter (100-240V 50/60hz)
