H3C Magic NX15
Gigabit Wi-Fi 6 Router
5GHz Wi-Fi 6
New Vertical Design
Stereoscopic Heat Dissipation
Full Gigabit Network Port
Wi-Fi Protocol: 5Ghz Wi-Fi6
Wireless Range: 1500Mbps
Coverage: 80-100m
CPU: 1000MHz
Maximum Access Capacity: 127
5GHz Wi-Fi 6
1500Mbps Dual-Band Gigabit
The 5GHz band supports Wi-Fi 6, which provides a 40% increase in wireless speed compared to the AC1200
New Vertical Design
The signal field strength is fuller and the transmission performance is more stable.
Adopting "I" design, the antenna is creatively adjusted to 180 compared to the traditional 90 "L", which increases the distance between the antenna and the metal PCB board to reduce the possibility of signal attenuation and effectively improve the signal transmission efficiency.
Stereoscopic Heat Dissipation
Improve cooling efficiency by adopting three-dimensional transparent cooling design and back overhang. With a large metal heat sink, effectively improving the cooling efficiency of the machine to ensure stable operation.
EasyMesh
Adapt to a variety of house types Whole-house Wi-Fi coverage. Freedom of movement without fear of dropping connections Wi-Fi coverage of complex house types and large house types can be expanded through mesh networking.
Multi-Protection
Internet Access for Peace of Mind
Multiple functions to keep your private network security, including Access allowlist/denylist, Guest Wi-Fi, Parental control.
IPv6
More IP addresses, faster access to information and more secure network applications.
Rigorous Testing Pursuit of Quality
Cooperate with octoScope, Spirent, Ixia and other international authoritative test instrument manufacturers
Simulate various home actual scenarios and extreme links Ensure that the router operates stably under different
conditions and environments.
Power supply stability test 220000 times
Hardware structure reliability test 69 times
Harsh environment test 1000 hours
Memory stress test 200000 times
Full load stability test 60 days
Flash memory device reliability test 100000 times
Technical specifications
Hardware
Port: 4 10/100/1000BASE-T Ethernet ports
Antenna: 4 external 5 dBi omnidirectional antennas
LED: System status LED on the rear
Dimensions: (H W D): 180 195 57.3 mm, (7.09 7.68 2.26 in)
Power consumption: 12 W
Cooling: Passive cooling
Certification: CE WEEE RoHS
Wireless
Wireless protocol: 2.4GHz: 802.11n/g/b , 5GHz: 802.11ax/ac/n/a
Spatial streams: 2.4GHz 2 2 MIMO, 5GHz 2 2 MIMO
Wireless bandwidth: 2.4G HT20/HT40, 5G HT20/HT40/HT80
Wireless rate: Simultaneous dual-band: 1501 Mbps, including 300Mbps on the 2.4GHz band and 1201 Mbps on he 5GHz band.
Wireless roaming: IEEE 802.11k/v
MU-MIMO: Upstream and downstream MU-MIMO
Software
Internet connection: Routing mode: DHCP/PPPoE/static IP, Bridge mode: Wired repeating/wireless repeating
Mesh: Support
IPv6: Support
Security: WPA3, anti-piggybacking, firewall, DMZ
Network management: Guest Wi-Fi, access allowlist and denylist, parental control at multiple time ranges, IP-based traffic control, scheduled Wi-Fi on/off
Special features: QoS traffic shaping, broadband password retrieval, packet fast-forwarding engine, virtual server, DDNS(NoIP,DynDNS), VPN(PPTP Client,L2TP Client)
Management method: H3C Magic APP management (iOS, Android), Web management
Fault diagnosis: Link detection, Internet access diagnosis
Operating environment
Operating temperature: 0 C to 40 C (32 F to 104 F)
Storage humidity: 10% to 90% RH, noncondensing
