H3C S5120V2-20P-LI L2 Ethernet Switch with 16x10/100/1000BASE-T Ports and 4x1000BASE-X SFP Ports
Abundant service capabilities
H3C S5120V2-LI switch series supports Internet broadband access, offers Gigabit access and 10G uplink for small to medium sized enterprises. It supports rich features such as Jumbo Frame, 802.1X, MAC authentication, Port security, LACP, 4K VLAN, 16K MAC and Black Hole MAC, etc. and abundant functions such as port-based priority mapping of layer 2 and layer 3, port-based mirror, redirection, port isolation, access control, port speed limit and rich IPV6 features, etc.
Intelligent Resilient Framework 2 (IRF2)
H3C S5120V2-LI switch series is pre-built with Intelligent Resilient Framework 2 (IRF2). IRF2 provides the following benefits:
High scalability: With IRF2, plug-n-play device aggregation can be achieved by adding one or more switches into the IRF2 stack and enabling IRF2 stacking on the new device. New devices can be managed with a single IP, and upgraded at the same time to reduce network expansion cost.
High reliability: The IRF2 patented 1: N backup technology allows each slave device in the IRF2 stack to serve as the backup of the master, creating control and data link redundancy, as well as uninterrupted layer-3 forwarding. This improves the reliability, avoids unplanned business downtime and serves to improve overall performance. When the master device fails, traffic remains uninterrupted.
Load balancing: IRF2 supports cross-device link aggregation, upstream and downstream can be connected to more than one physical link, which creates another layer of network redundancy and boosts the network resource utilization.
Availability: H3C Implements IRF2 through standard Gigabit Ethernet (1GE) ports or Ten Gigabit Ethernet (10GE) ports which allocates bandwidth for business and application access and reasonably splits local traffic and upstream traffic. IRF2 rules not only able to obey within and across the rack, but also across the LAN.
Comprehensive security control policies
H3C S5120V2-LI switch series supports innovative single-port multi-authentication function, the access authentication modes supported by different clients are different. For example, some clients can only perform MAC addresses Authentication (such as the printer terminal), and some user host for 802.1X authentication, and some user hosts only want to access through the Web portal authentication. In order to flexibly adapt to the multi-authentication requirements of the network environment, the S5120V2-LI switch series support single-port multi-authentication unified deployment.
ARP attack and ARP virus are major threats to LAN security, so the S5120V2-LI switch series
comes with diverse ARP protection functions such as ARP Detection to challenge the legitimacy of client, validate the ARP packets, and set a speed limit for ARP to prevent ARP swarm attacks from targeting CPU.
H3C S5120V2-LI switch series support EAD (End User Admission Domination) function. Once working with the iMC (intelligent Management Centre) system, EAD integrates terminal security policies, such as anti-virus and patch update, into network access control and access right control policies to form a cooperative security system. By checking, isolating, updating, managing, and monitoring access terminals, EAD changes passive, single point network protection to active, comprehensive network protection, and changes separate management to centralized management, enhancing the network capability for preventing viruses, worms, and new threats.
Abundant QoS policies
The S5120V2-LI switch series supports packet filtering at Layer 2 through Layer 4, and traffic classification based on source MAC addresses, destination MAC addresses, source IP addresses, destination IP addresses, TCP/UDP port numbers, protocol types, and VLANs. It supports flexible queue scheduling algorithms based on ports and queues, including strict priority (SP), weighted round Robin (WRR) and SP+WRR. The S5120V2-LI switch series enables committed access rate (CAR) with the minimum granularity of 8 kbps. It supports port mirroring in the outbound and inbound directions, to monitor the packets on the specific ports, and to mirror the packets to the monitor port for network detection and troubleshooting.
Excellent manageability
The H3C S5120V2-LI switch series makes switch management with ease with the support of SNMPv1/v2/v3, which can be managed by NM platforms, such as Open View and iMC. With CLI and Telnet switch management is made easier. And with SSH 2.0 encryption, switch management security is enhanced.
Rich Layer 3 routing features
H3C S5120V2-LI switch series supports static routing, RIP, RIPng, OSPF V1/V2/V3.
