Harwin (M20-7890646) PCB Receptacle, Board-to-Board, 2.54 mm, 1 Rows

PCB Receptacle, Board-to-Board, 2.54 mm, 1 Rows, 6 Contacts, Through Hole Mount,M20Product OverviewThe M20-7890646 is a 6-contact 2.54mm female SIL Board-to-board Socket with 100%tin over nickel phosphor bronze contacts, 100% tin over nickel platedtermination and black UL94V-0 polyamide (nylon) 6T housing. The M20 seriesreceptacle has 3mm solder PC tails, horizontal connector orientation, PCtail/through board connection type and side entry style. It is suitable for usewith 0.64mm square mating pin size. Two point solder fixing for connectorrigidity. Suitable for interconnecting board to board. The socket is a boxsection design with a latch to locate and hold in an insulated housing.3A Current rating20mR Maximum contact resistance1000MR Minimum insulation resistance500VAC for one minute Voltage proofApplicationsCommercial, IndustrialProduct InformationConnector Systems: Board-to-BoardPitch Spacing: 2.54mmNo. of Contacts: 6ContactsContact Termination Type: Through HoleConnector Mounting: Through Hole MountNo. of Rows: 1RowsProduct Range: M20Contact Material: Phosphor BronzeContact Plating: Tin Plated Contacts
