Harwin (M50-3120545) PCB Receptacle, Board-to-Board, 1.27 mm, 2 Rows

PCB Receptacle, Board-to-Board, 1.27 mm, 2 Rows, 10 Contacts, Surface Mount,Archer M50Product OverviewThe M50-3120545 is a 10-contact 1.27mm female DIL Board-to-board Socket withgold plated phosphor bronze contacts, gold plated termination and black UL94V-0LCP housing. The M50 series receptacle has vertical connector orientation,surface mount (SMT) connection type and top entry style. It is suitable for usewith 0.4mm square mating pin size.1A Current rating30mR Maximum contact resistance1000MR Minimum insulation resistance300VAC, 500VDC for one minute Voltage proof100 cycles Minimum durabilityApplicationsCommercial, IndustrialProduct InformationConnector Systems: Board-to-BoardPitch Spacing: 1.27mmNo. of Contacts: 10ContactsContact Termination Type: Surface Mount StraightConnector Mounting: Surface MountNo. of Rows: 2RowsProduct Range: Archer M50Contact Material: Phosphor BronzeContact Plating: Gold Plated Contacts
