Harwin (M80-8420242) Pin Header, Board-to-Board, Wire-to-Board, 2 mm

Pin Header, Board-to-Board, Wire-to-Board, 2 mm, 1 Rows, 2 Contacts, ThroughHoleProduct OverviewThe M80-8420242 is a 2-contact male Datamate L-Tek SIL PCB Plug with blackUL94V-0 polyamide (nylon) 46 housing, gold plated phosphor bronze contacts and100% tin over nickel plated termination. The M80 series connector has horizontalconnector orientation and PC tail/through board connection type. Locking latchestooling required to separate mated connectors. Supplied with strain reliefstraps (M80-0030006). It is suitable for Ø0.5mm mating pin size. The connectoris intended for use as a low voltage connector in high packing densityelectronic equipment. The connector is polarised to prevent mismatching.3A (at 25°C), 2.2A (at 85°C) Current rating120VAC/DC Working voltage20mR (initial), 25mR (after conditioning) Maximum contact resistance1000MR (initial), 100MR (after conditioning) Minimum insulation resistance500 operations DurabilityApplicationsIndustrialProduct InformationConnector Systems: Board-to-Board, Wire-to-BoardPitch Spacing: 2mmNo. of Rows: 1RowsNo. of Contacts: 2ContactsContact Termination Type: Through HoleProduct Range: Datamate L-Tek M80Connector Shroud: ShroudedContact Material: Phosphor BronzeContact Plating: Gold Plated Contacts
