Harwin (M80-8530842) Pin Header, Board-to-Board, Wire-to-Board, 2 mm

Pin Header, Board-to-Board, Wire-to-Board, 2 mm, 2 Rows, 8 Contacts, ThroughHoleProduct OverviewThe M80-8530842 is a 8-contact male Datamate L-Tek DIL PCB Plug with blackUL94V-0 polyamide (nylon) 46 housing, gold plated phosphor bronze contacts and100% tin over nickel plated termination. The M80 series connector has 3mm PCtail, vertical connector orientation and PC tail/through board connection type.Locking latches tooling required to separate mated connectors. It is suitablefor Ø0.5mm mating pin size. The connector is intended for use as a low voltageconnector in high packing density electronic equipment. The connector ispolarised to prevent mismatching.3A (at 25°C), 2.2A (at 85°C) Current rating800VAC/DC Working voltage20mR (initial), 25mR (after conditioning) Maximum contact resistance1000MR (initial), 100MR (after conditioning) Minimum insulation resistance500 operations DurabilityApplicationsIndustrialProduct InformationConnector Systems: Board-to-Board, Wire-to-BoardPitch Spacing: 2mmNo. of Rows: 2RowsNo. of Contacts: 8ContactsContact Termination Type: Through HoleProduct Range: Datamate L-Tek M80Connector Shroud: ShroudedContact Material: Phosphor BronzeContact Plating: Gold Plated Contacts
