Fiber Cables to be used with HDMI over Fiber extenders is at LC to LC Fiber Cables
Note!! This Fiber Extender Set can use any Fiber or copper SFP. It has a BiDi (Bi-Directional) Single Mode Simplex SFP set included as at 3km Single Mode Bi-Directional SFP Transceiver Module SET for transmission distances up to 3km. If longer ranges required the SFP set needs to be replaced by one that allows longer transmission distances. Multimode SFP's can also be used on this HDBitT Fiber Extender.
| Power Adapter | DC 5V 2A (for TX and RX) |
| DDC signal voltage | 5Vp-p |
| Transmission speed | 1.25 Gbps |
| Supported HDMI input Resolutions | 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz |
| Supported HDMI output Resolutions | 480p@60Hz, 576p@50Hz, 720p@50/60Hz, 1080p@50/60Hz |
| Centre wavelength | 1310nm |
| Connecting interface | SFP - GE - BIDI - 40km - T1550/R1310 - LC - I - D10 |
| Fibre type | Single mode fibre |
| Linked circuit loss | <15dB |
| output power | >10dBm |
| Receive sensitivity | <33dBm |
| IR remote control | Supports 38kHz |
| Power Consumption | TX: 5W RX: 5W |
| Dimension | 13 x 8.5x 2.4cm |
