HDMI TO SDI CONVERTER: HDMI-SDI
SDI to HDMI Converter Uses a Unique Technology
Delivering Clear and Vivid Pictures on Your HDMI Displays
Supports Auto Resolution Detection of HD-SDI, SD-SDI and 3G-SDI
Embedded SDI/HD-SDI Audio is Supported in the HDMI Output Allowing a Convenient Single Cable Audio/Video Connection
Supports Resolutions up to 1080P Gives this Unit a Superior Quality while Maintaining its High Performance
Features
SDI Input, HDMI Output
Auto Detects Resolution of HD-SDI, SD-SDI and 3G-SDI
Supports Resolutions up to 1080P
Full HDMI Supported with Embedded Audio
Date rate: 270Mb/s, 1.485Gb/s, 2.97Gb/s
SD-SDI Signal is as Far as 460 Meters Away HD-SDI is as Far as 230 Meters Away
Plug and play:
Supports Resolutions: SD 525i, 625i, HD720P@24HZ, 720P@25HZ, 720P@30H
720P@50HZ, 720P@60HZ, HD 1080i@50HZ; 1080i@60HZ; HD 1080P@24HZ, 1080P@25HZ, 1080P@30HZ, 1080P@50HZ,1080P@60HZ
Specification
Number of SDI In :1
Number of HDMI Out :1
Support :HDCP 1.2 Compliant, Deep Color 36bit, 1080p, 3D Display
DTV/HDTV :1080i, 720p, 720i, 576p, 576i, 480p, 480i, 1080p
VGA :1920x1080, 1600x1200, 1360x768, 1280x1024, 1280x800, 1280x768, 1280x720, 1024x768, 800x600, 640x480
Video Input Signal :SD HD 3G SDI
Other Ports :DC Port
Dimensions /:95x43x23
Net Weight (g) :125
Power :5V DC Power Supply
