Features:
Using the oscillometric blood pressure measurement,Accurately measure the blood pressure.
LCD digital display,legible.
Intelligent pressure.
WHO warning message function.
Double mode,each of the 99 set of measurements of memory.
No operation in 1 minutes automatic shutdown.
An irregular heartbeat measurement.
The clock feature.
The overpressure protection function.
Specifications:
ModelJWS-700
Method of measurementNon-invasive, ocsillometric blood pressure infaltion measurement at wrist for wrist circumference at 12.5-20.5cm
Display range0-300mmHg
Measuring rangeSystolic 50-250 mmHg, diastolic 40-180 mmHg, pulse 40-200 beats/minute
Measuring accuracy+/- 3 mmHg
Measuring uncertainty+/- 8 mmHg
Sets of Memory2 * 99 memory
Operation voltageDC 3V
MCU operation voltage4.0V
Low Batt. WarningAt 2.2V
Low Batt.At 2.0V ('LO' shown)
Current showing memory<10mA
Shutdown current<100μA
Max. auto-pressure285mmHg
Over-votage protection290mmHg
Auto power-off timeMemory mode, no measurement for 30s
ERR mode, no mearurement for 120s
Measurement end,120s
Dimension74mm (L) x 85mm (W) x 25mm (H)
Weight (w/o batt)120g
Cuff sizeWrist circumference 12.5 - 20.5 cm
Operating temperature+ 10 C to + 40 C, <= 85% RH
Storage temperature- 10 C to + 50 C, <= 85% RH
Power supply2 * 1.5V AAA battery (not included)
Battery lifeApprox. 300 times measurements, varied by blood pressure level or inflation pressure
MaterialPlastic
Product sizeApprox. 7.4 * 8.5 * 2.5cm / 2.9 * 3.3 * 1in (L * W * H)
Product weightApprox. 130g / 4.6oz
Package sizeApprox. 15 * 12 * 10cm / 5.9 * 4.7 * 3.9in (L * W * H)
Package weightApprox. 313g /11oz
Notice:
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Please consider you mind or not before buying.
Package List:
1 * Blood Pressure Monitor
1 * Carry Box
1 * User Manual (English)
