Heart Rate Monitor Fingertip Pulse Oximeter

 Combines blood oxygen probe and heart rate in single display module

Lightweight and portable, convenient to carry

Easy to use with low-power consumption

Oxygen saturation display

Pulse rate and bar graph display

Pulse wave display

Low-voltage indicator

Four directions display modes

Automatically powers off in 5 seconds when finger removed

Color: Blue + black + white

 Material: PVC

 Display Screen: 1.1" color OLED display, resolution: 96 x 64

SpO2: Measurement range: 70~99%; Resolution: 1%; Accuracy: 70%~99% +/- 2%, unspecified <70%

Pulse rate: Measurement range: 30~240bpm, Resolution: 1bpm, Accuracy: +/- 2bpm or +/- 2% (select larger)

 Power: 2 x AAA alkaline batteries (not included)

 Power consumption: <=30mA

Working voltage: DC 3V

 Measurement principle: the principle of the oximeter is as follows:

 An experience formula of data process is established by exerting Lambert Beer Law according to Spectrum Absorption Characteristics of Reductive hemoglobin (R Hb) and oxyhemoglobin (O2 Hb) in glow and near-infrared zones; Operation principle of the instrument is to combine Photoelectric Oxyhemoglobin /inspection Technology with Capacity Pulse Scanning and Recording Technology, so that two lights with different wavelength (660nm glow and 940nm near infrared light) can be focused onto human nail through perspective clamp finger-type sensor.

Then measured signal can be obtained by a photosensitive element, information acquired through which will be shown on two groups of LEDs through process in electronic circuits and microprocessor
 Two color OLED display, more display modes

 Low-power consumption, continuously four directions adjustable
 Low voltage indicator
 Automatically power off in 8 seconds when there is no signal
 Compact design, lightweight for convenient to carry
 Can be used in hospital, home, community medical treatment, sports healthcare, etc.
 Suitable for heart disease patient, The patient with hypertension, diabetes mellitus patient, especially the old man, pregnant woman, professional athlete etc.

 Packing List:
 1 x Oximeter
 1 x Strap
 1 x English user manual

Dimensions: 2.28 in x 1.42 in x 1.22 in (5.8 cm x 3.6 cm x 3.1 cm)
