High Power 10A DC-DC Step Down Power Supply Module Constant Voltage Current Solar Charging 3.3/5/12/

Description: Module Name: 10A Pressure Reduction Constant Pressure Constant Current Modular nature: synchronous rectification of non-isolated buck module (BUCK) Input voltage: 4-32V (limit 36V), please reserve the voltage margin. Output voltage: 1.2-32V continuously adjustable (default output 5V, if you need other voltage please explain to the palm. ) Default shipment is adjustable output, (5V/6A when shipment) Minimum differential pressure: 1V Output current: 0.4-10A long time natural heat dissipation within 6A, temperature does not exceed 60 degrees. When the ambient temperature is high, please reduce the amount of use. Output constant current range: 0.3-10A Working temperature: - 40 ~+85 degrees Working frequency: 150 KHz Conversion efficiency: up to 98% (efficiency is related to input, output voltage, current and voltage difference) Short-circuit protection: with (current limiting constant current value) Over-temperature protection: there is (automatic reduction of output current after over-temperature) Input Reverse Connection Protection: No (If necessary, enter diode in series in input) Output Back Irrigation Protection: No (If needed, please connect the output diode in series, add the anti-back diode between the module output and the battery when charging application, otherwise the module will be damaged.) Installation: 4 3mm screws Module size: 60 mm long, 26 mm wide and 20 mm high Module weight: about 26G Connection mode: terminal, welding-free, IN as input, OUT as output. Package included:

1 x High Power 10A DC-DC Step Down Module
