Parameter | Symbol | Maximum Rating | Unit |
Continuous Forward Current | IF | 350 | mA |
Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width) | IFP | 500 | mA |
Reverse Voltage | VR | 5 | V |
Power Dissipation | PD | 1 | W |
Electrostatic Discharge | ESD | 1000 | V |
Operating Temperature Range | TOPR | -25C to +80C | |
Storage Temperature Range | TSTG | -35C to +100C | |
Lead Soldering Range | TSOL | 260C |
Parameter | Symbol | Color | Min. | Typ. | Max | Unit | Test Condition |
Forward Voltage | VF | R | 2 | 2.2 | 2.4 | V | If = 350mA |
G | 3 | 3.2 | 3.4 | If = 350mA | |||
B | 3 | 3.2 | 3.4 | If = 350mA | |||
Luminous Flux | R | 40 | 45 | 50 | Lm | If = 350mA | |
G | 60 | 65 | 70 | If = 350mA | |||
B | 15 | 20 | 25 | If = 350mA | |||
Dominant Wavelength | Wld | R | 620 | 623 | 625 | nm | If = 350mA |
G | 520 | 522 | 525 | If = 350mA | |||
B | 460 | 462 | 465 | If = 350mA | |||
Reverse Current | IR | 10 | A | Vr = 5V | |||
Viewing Angle | 21/2 | 120 | 14 | deg | If = 350mA | ||
Recommended Forward Current | IF(rec) | RGB | 350 | mA |
