| Specification | Details |
|---|---|
| Display | |
| Screen Size | 23.8 inch |
| Active Display Area | 527.04 mm (H) × 296.46 mm (V) |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.2745 (H) mm × 0.2745 (V) mm |
| Brightness | 250 cd / m² |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Depth | 8 bit |
| Contrast Ratio | 4000 : 1 |
| Response Time | 6.5 ms (typ) (G to G) OD, 5 ms |
| Refresh Rate | 60 Hz |
| Haze | Anti-Glare, 3H (Without Haze) |
| Reliability | 7 × 24 H |
| Colour Gamut | 72% NTSC |
| Interface | |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1 |
| Video & Audio Output | None |
| Data Transmission Interface | None |
| Control Interface | None |
| Power | |
| Power Supply | DC 12 V, 2.5 A |
| Power Consumption | 30 W |
| Standby Consumption | 0.5 W |
| Working Environment | |
| Working Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity | 20% to 80% RH (Non-Condensing) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Storage Humidity | 20% to 80% RH (Non-Condensing) |
| General | |
| Casing Material | Plastic |
| VESA | 100 mm × 100 mm (4 M4 × 10 mm) |
| Bezel Width | 1.8 mm (top / left / right), 21.4 mm (bottom) |
| Product Dimensions (W × H × D) | Without stand: 538.40 (W) mm × 326.35 (H) mm × 37.50 (D) mm With stand: 538.40 (W) mm × 407.10 (H) mm × 186.37 (D) mm |
| Package Dimensions (W × H × D) | 600 (W) mm × 408 (H) mm × 94 (D) mm |
| Net Weight | 2.634 ± 0.5 kg |
| Gross Weight | 3.340 ± 0.5 kg |
| Packing List | Monitor × 1, Base component × 1, Power adapter (12 V, 2.5 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1 |
| Remarks | If the appearance and parameters in this specification vary from the actual product, the later prevails. You can also consult local sales staff. |
