Camera
Image Sensor
2 MP CMOS
Max. Resolution
1920 (H) `d7 1080 (V)
Min. Illumination
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s
Day & Night
ICR
Angle Adjustment
Pan: 0 to 360`b0, Tilt: 0 to 90`b0, Rotation: 0 to 360`b0
Signal System
PAL/NTSC
Lens
Lens Type
3.6 mm, 6 mm, 8 mm, 12 mm fixed lens
Focal Length & FOV
3.6 mm, horizontal FOV: 79.6`b0, vertical FOV: 43.5`b0, diagonal FOV: 93.7`b0 6 mm, horizontal FOV: 51.9`b0, vertical FOV: 30`b0, diagonal FOV: 58.8`b0 8 mm, horizontal FOV: 39.9`b0, vertical FOV: 21.9`b0, diagonal FOV: 46.5`b0 12 mm, horizontal FOV: 24.6`b0, vertical FOV: 13.9`b0, diagonal FOV: 28.1`b0
Lens Mount
M12
Image Parameters Switch
STD/HIGH-SAT
Image Settings
Brightness, Sharpness, Smart IR
Frame Rate
TVI: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC
Day/Night Mode
Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR)
Digital WDR
Image Enhancement
BLC, HLC
White Balance
Auto/Manual
AGC
Yes
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
General
Material
Main Body: Metal Enclosure: Plastic
Dimension
75.4 mm `d7 78.9 mm `d7 184.9 mm (2.97" `d7 3.10" `d7 7.28")
Weight
Approx. 300 g (0.66 lb.)
Operating Condition
'-40 `b0C to 60 `b0C (-40 `b0F to 140 `b0F), humidity: 90% or less (non-condensation)
Communication
HIKVISION-C
Language
English
Power Supply
12 VDC `b1 25%
Consumption
Max. 4.7 W
IR Range
Up to 80 m
Approval
Protection
IP67
