PLEASE NOTE: THIS IS NOT AN IP/WIFI/WIRELESS CAMERA
USE A HIKVISION DVR WHICH SUPPORT SMART LIGHTING FUNCTIONALITY.
2MP Smart Hybrid Light Fixed Mini Bullet Camera
High quality imaging with 2 MP, 1920 `d7 1080 resolution
Fixed focal lens, 2.8 and 3.6 mm optional
Up to 20 m IR distance for bright night imaging
Up to 20 m white light distance for bright night imaging
One port for 4 switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP67)
Camera
Image Sensor
2 MP CMOS
Max. Resolution
1920 (H) d7 1080 (V) Min. Illumination 0.02 Lux @ (F2.2, AGC ON), 0 Lux with IR Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s Day & Night ICR Angle Adjustment Pan: 0 to 360b0, Tilt: 0 to 90b0, Rotate: 0 to 360b0
Signal System
PAL/NTSC
Lens
Lens Type
Fixed focal lens, 2.8 and 3.6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV: 97b0, vertical FOV: 54b0, diagonal FOV: 113`b0
3.6 mm, horizontal FOV: 77b0, vertical FOV: 43b0, diagonal FOV: 90`b0
Lens Mount
M12
Illuminator
Supplement Light Type
White Light;IR
Supplement Light Range
IR : Up to 20 m
White Light : Up to 20 m
Image Parameters Switch
STD/HIGH-SAT/HIGHLIGHT
Image Settings
Brightness, Sharpness, Smart IR
Frame Rate
TVI: 1080p @ 30 fps, 1080p @ 25 fps
AHD: 1080p @ 30 fps, 1080p @ 25 fps
CVI: 1080p @ 30 fps, 1080p @ 25 fps
CVBS: PAL/NTSC
Wide Dynamic Range (WDR)
Digital WDR
Image Enhancement
DWDR/BLC/HLC/Global
White Balance
Auto/Manual
AGC
Yes
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
General
Material
Plastic
Dimension
d870 mmd7 138.8 mm (d82.76" x 5.46") Weight Max. 150 g (0.33 lb.) Operating Condition -40b0C to 60 b0C (-40b0F to 140 b0F). Humidity: 90% or less (non-condensation) Communication HIKVISION-C Language English Power Supply 12 VDCb1 25%, Max. 3.2 W
xYou are recommended to use one power adapter to supply the power for one camera.
Approval
Protection
IP67
What's in the box
1x Hikvision 2MP Smart Hybrid Light Fixed Mini Bullet Camera
