HIKVISION DS-E04HGHI-D 4-ch 1080p Lite 1U H.265 eSSD DVR
Key Features:
eSSD Technology: Powered by efficient eSSD technology.
Deep Learning: Motion Detection 2.0 for human and vehicle classification, reducing false alarms.
Scene-Adaptive Bitrate Control: Efficient video compression based on scene changes.
1080p Lite Encoding: Supports up to 1080p Lite at 30 fps.
Low Power Consumption: Energy-efficient operation.
Audio via Coaxial Cable: Supports audio transmission through coaxial cables.
Motion Detection 2.0:
Human/Vehicle Analysis: Deep learning-based motion detection for accurate classification.
False Alarm Reduction: Minimizes false alarms caused by non-relevant objects.
Quick Search: Allows search by object or event type.
Video and Audio Capabilities:
IP Video Input:
1 channel
Supports up to 1080p resolution
Compatible with H.265+/H.265 IP cameras
Analog Video Input:
4 channels
BNC interface (1.0 Vp-p, 75 `d9) with coaxitron support
Supported Input Formats:
HDTVI: 1080p25, 1080p30, 720p25, 720p30
AHD: 1080p25, 1080p30, 720p25, 720p30
HDCVI: 1080p25, 1080p30, 720p25, 720p30
CVBS: Supported
Video Output:
HDMI Output:
1 channel, up to 1920 `d7 1080/60 Hz
VGA Output:
1 channel, up to 1920 `d7 1080/60 Hz
Output Mode:
HDMI/VGA simultaneous output
Audio Input:
4 channels via coaxial cable
Audio Output:
1 channel via HDMI
Synchronous Playback:
4 channels
Recording Specifications:
Video Compression: H.265 Pro/H.265
Encoding Resolution: 1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA
Frame Rate:
Main stream: 1080p Lite/720p@25 fps (P)/30 fps (N)
Sub-stream: 4CIF@15 fps; CIF/QVGA@25 fps (P)/30 fps (N)
Video Bitrate: Scene-adaptive bitrate control for optimal storage use.
Stream Type: Video or Video & Audio
Audio Compression: G.711u
Audio Bitrate: 64 Kbps
Network Specifications:
Total Bandwidth: 64 Mbps
Incoming Bandwidth: 4 Mbps
Remote Connections: Up to 32
Network Protocols: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP`99, HTTPS
Network Interface: 1 RJ45 10/100 Mbps self-adaptive Ethernet port
Auxiliary Interface:
Storage Capacity: Built-in 512 GB eSSD (480 GB available)
USB Interface:
2 USB 2.0 ports (rear panel)
Alarm In/Out: Not available
General Specifications:
Power Supply: 12 VDC, 1 A
Power Consumption: 5.4 W (with eSSD)
Operating Temperature: -10 `b0C to 45 `b0C (14 `b0F to 113 `b0F)
Operating Humidity: 10% to 90%
Dimensions: 151 `d7 121 `d7 46 mm (5.94 `d7 4.76 `d7 1.81 inch)
Weight: 0.5 kg (with eSSD, 1.1 lb.)
