Hikvision Access Controller with 2-door Control Support DS-K2702WX-E1

Features

• Supports 2-door control. It can extend up to 62 DS-K2M002X access modules, and up to 126 doors can be controlled
• Downstream RS-485 redundancy wiring design to ensure communication stability. 5-ch downlink RS-485 interface supports two applications: 1. When 4-ch RS-485 communication, the 5th RS-485 can be used as a redundant application; 2. 4-ch RS-485 forms 2 groups of dual-bus loops with physical isolation. It is recommended that you do not have more than 16 access modules attached to each loop bus.
• Web configuration management. All configurations can be realized via web without software application
• Supports professional access control applications such as multi-door interlocking and anti-passback
• Supports backup battery access. Charging and discharging are available
• It has status indicators such as power supply, communication and operation, which is convenient for equipment health detection
• Powers supply by PoE, and Wi-Fi is available

Technical Specification

Operating system: Linux

Wired network: 1x 10/100/1000 Mbps self-adaptive

Wi-Fi: Support, 2.4 G, 802.11b/g/n

Interface

• Network interface: 1
• Lock control: 2
• Exit button: 2
• Door contact input: 2
• Alarm input: 4
• Alarm output: 4
• TAMPER: 1
• RS-485: 7x 2 for card reader, 5 for access modules (4 for communication, each interface can connect up to 16 access modules; 1 for redundancy)
• Wiegand: 4x standard 26/34 input, supports custom Wiegand settings
• USB: 1x USB 2.0
• PoE: 1x Supports 802.3at
• Fire interface: 1

Capacity

• User capacity: 100,000
• Fingerprint capacity: 10,000
• Card capacity: 200,000
• Event capacity: 600,000
• Linked card reader capaciry: 4 RS-485 card readers (OSDP protocol) and 4 Wiegand card readers
• Linked door capacity: Self: 2 doors, Extended: up to 126 doors (connected with 62 access modules)

Authentication

• Fingerprint recognition duration: < 1 s

General

• Indicator: 11 indicators, 1 for indicating power status, 1 for running status, 1 for wired network status, 1 for Wi-Fi status, 5 for RS-485 status, and 2 for door status
• Battery: Charge and discharge
• Power supply: 100 VAC to 240 VAC, standard PoE
• Power consumption: 72 W
• Installation: Wall mounting
• Lock Power Out: 12 V, 2A

Function

• Configuration via Web browser: Support
• Multi-factor authentication: Support
• First person in: Support
• Anti-passback: Support 32 routes (64 card readers each)
• Multi-door interlocking: Support 32 groups (32 doors each)
