Hikvision DS-PDMC-EG2-WE AX PRO Wireless Magnetic Contact
The Hikvision DS-PDMC-EG2-WE is a wireless magnetic contact designed for Hikvision AX PRO alarm systems. It is used to detect the opening of doors or windows, providing early intrusion alerts when an entry point is opened or tampered with.
With its slim and discreet design, the DS-PDMC-EG2-WE is ideal for residential, retail, office, and small business security installations. It can be fitted to doors, windows, and other access points, helping secure vulnerable areas without affecting the appearance of the installation.
The detector uses Hikvision Tri-X wireless technology on the 868MHz frequency, offering secure two-way communication, AES-128 encrypted transmission, and frequency hopping to help reduce interference and improve signal reliability. With a wireless range of up to 1.6km in open space, it provides dependable performance for AX PRO alarm systems.
The DS-PDMC-EG2-WE also supports remote configuration through the app, multiple enrolment methods, signal strength indication, environmental temperature indication, and front and rear tamper protection. Its CR123A battery offers up to 5 years of standby operation, making it a low-maintenance solution for professional alarm installations.
Key Features:
-
Wireless magnetic contact for Hikvision AX PRO systems
-
Detects door and window opening
-
Maximum detection gap: 43mm
-
Slim, discreet design for neat installation
-
Tri-X two-way wireless communication
-
868MHz transmission frequency
-
AES-128 encrypted wireless transmission
-
Frequency hopping against interference and jamming
-
Up to 1.6km wireless range in open area
-
Front and rear tamper protection
-
Signal strength indicator
-
Environmental temperature indicator
-
Remote configuration through the app
-
Multiple enrolment methods: power-up, remote ID, and QR code
-
Battery powered with CR123A battery
-
Up to 5 years standby battery life
-
Indoor application
-
Ideal for doors, windows, offices, homes, shops, and alarm system upgrades
Why Choose This Detector?
The Hikvision DS-PDMC-EG2-WE is a reliable and easy-to-install wireless door and window contact for AX PRO alarm systems. It offers secure wireless communication, long battery life, tamper protection, and discreet installation, making it a practical choice for strengthening perimeter security in both home and business environments.
