Hikvision DS-PDTT15AM-LM-WE AX PRO Wireless Triple Signal Detector
The Hikvision DS-PDTT15AM-LM-WE is a professional wireless outdoor triple-signal detector designed for Hikvision AX PRO alarm systems. Combining passive infrared and microwave detection with active IR anti-masking, pet immunity, IP65 weather resistance, and Tri-X wireless communication, it delivers reliable outdoor intrusion detection for homes, businesses, and perimeter security applications.
Product Description
Protect outdoor areas with confidence using the Hikvision DS-PDTT15AM-LM-WE AX PRO Wireless Triple Signal Detector. Built for demanding perimeter security, this detector combines PIR and microwave detection technologies to accurately identify human movement while helping reduce false alarms caused by pets, environmental changes, or outdoor interference.
With a detection range of up to 15 metres and 90° @ 180° adjustable coverage, the DS-PDTT15AM-LM-WE is ideal for monitoring driveways, gardens, boundary walls, patios, entrances, walkways, and commercial outdoor areas. Its 92 detection zones and digital tri-signal logic provide intelligent detection performance, while pet immunity of up to 40 kg makes it suitable for properties with dogs or other small animals.
The detector features active IR anti-masking protection to detect attempts to block or cover the sensor. It also includes sealed optics, digital temperature compensation, and a white light filter of up to 10,000 lux, ensuring dependable performance in bright sunlight and changing outdoor conditions.
Designed for Hikvision AX PRO systems, the DS-PDTT15AM-LM-WE uses Tri-X two-way wireless communication with AES-128 encryption and frequency hopping for stable, secure transmission. With IP65 weather resistance and long battery life, it offers a professional-grade outdoor detection solution with flexible wireless installation.
Key Features:
-
Wireless outdoor triple-signal detector
-
Designed for Hikvision AX PRO alarm systems
-
PIR and microwave detection technology
-
Detection range up to 15 m
-
90° @ 180° adjustable coverage
-
92 detection zones for accurate movement detection
-
Digital tri-signal logic processing
-
Active IR anti-masking protection
-
Pet immunity up to 40 kg
-
IP65 weather-resistant outdoor housing
-
Digital temperature compensation
-
Sealed optics for improved outdoor reliability
-
White light filter up to 10,000 lux
-
Tri-X two-way wireless communication
-
AES-128 encrypted wireless transmission
-
Frequency hopping against interference and jamming
-
Front and rear tamper protection
-
Multiple enrolment methods for easy installation
-
Battery-powered for flexible placement
-
Ideal for perimeter and outdoor intrusion detection
Technical Specifications
Brand: Hikvision
Model: DS-PDTT15AM-LM-WE
Product Type: AX PRO Wireless Triple Signal Detector
Application: Outdoor
Detection Method: Passive Infrared and Microwave
Detection Range: 15 m
Detection Coverage: 90° @ 180° adjustable
Detection Zones: 92
Detectable Speed: 0.3 m/s to 2 m/s
Sensitivity: Auto / Low
Microwave Frequency: 24 GHz
Pet Immunity: Up to 40 kg
Anti-Masking: Active IR anti-masking
White Light Filter: Up to 10,000 lux
Digital Processing: Tri-signal logic
Digital Temperature Compensation: Supported
Sealed Optics: Supported
Wireless Technology: Tri-X Wireless
Transmission Method: Two-way RF wireless
RF Frequency: 868 MHz
Transmission Security: AES-128 encryption
Frequency Hopping: Supported
Wireless Range: Up to 1.6 km in open space
Tamper Protection: Front and rear
Power Supply: Battery powered
Battery Type: 5 × CR123A
Battery Life: Up to 5 years
Operating Temperature: -25°C to 60°C
Operating Humidity: 10% to 90%
IP Rating: IP65
Dimensions: 75 mm × 202 mm × 73 mm
Weight: Approx. 600 g
Mounting Height: 0.8 m to 1.2 m
Mounting Method: Wall mount
What's in the Box:
Ideal For:
-
Outdoor perimeter protection
-
Residential driveways and gardens
-
Boundary walls and walkways
-
Patios and entrance areas
-
Commercial outdoor security
-
Warehouses and business premises
-
AX PRO wireless alarm installations
-
Properties requiring pet-tolerant outdoor detection
