Hikvision Multi-channel SMPS 12V 60W 8-ch CCTV Power Supply DS-2FA1205-C8(EUR)

Hikvision Multi-channel SMPS 12V 60W 8-ch CCTV Power Supply DS-2FA1205-C8(EUR)

Features

• 60 W, 12 VDC/1 A max per channel, max total current is 5 A

• Over current/short circuit/over voltage protection

• Good EMC performance

• Compact size; applicable to cameras

• 150 to 285 VAC wide voltage input

Technical Specification

Parameters

• Appearance: White

• Dimension: 144 mm × 109.5 mm × 33 mm (5.67" × 4.31" × 1.30")

• Operating Conditions: 0°C to 40°C (32°F to 104°F), Humidity: 10% to 95% (non-condensing)

• LED Indicator: Green

• Input: 150 to 285 VAC, 47 Hz to 63 Hz

• Output: 12 VDC/1 A per channel

• Ripple & Noise 150 MVp-P: 0.15 Vp-p (150 mV)

• AC Input Connector: C8

• DC Output Connector: DC Plug: grid terminal

• Storage Conditions: -40°C to 80°C (-40°F to 176°F), Humidity: 5% to 95% (non-condensing)

• Cable Length Compensation:

  Normal: 12 VDC

  Long: 13.5 VDC

  Ex-Long: 15 VDC
