1 Megapixel high-performance CMOS
Analog HD output, up to 720P resolution
True Day/Night
DNR, Smart IR
Up to 20m IR distance
IP66 weatherproof
Specifications
Camera
Image Sensor1MP CMOS Image Sensor
Signal SystemPAL/NTSC
Effective Pixels1296(H)*732(V)
Min. illumination0.1 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time1/25(1/30)s to 1/50,000s
Lens
2.8mm, 3.6mm, 6mm optional
Angle of View: 70.9`b0(3.6mm), 92`b0(2.8mm), 56.7`b0(6mm)
Lens MountM12
Day & NightICR
Angle AdjustmentPan: 0 - 360`b0, Tilt: 0 - 75`b0, Rotation: 0 - 360`b0
SynchronizationInternal synchronization
Video Frame Rate720p@25fps/720p@30fps
HD Video Output1 Analog HD output
S/N Ratio`a3`be62dB
General
Operating Conditions-40 `a1`e3C - 60 `a1`e3C (-40 `a1`e3F - 140 `a1`e3F), Humidity 90% or less (non-condensing)
Power Supply12 VDC`a1`c015%
Power ConsumptionMax. 4W
Protection LevelIP66
IR RangeUp to 20m
Dimensions`d689.5 `d7 69.8 mm(`d63.52” `d7 2.75”)
Weight280 g
