Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

Quick search by object or event type is supported;

2-ch

Up to 5 MP resolution

Support H.265+/H.265 IP cameras

16-ch

BNC interface (1.0 Vp-p, 75 ), supporting coaxitron connection

Main stream:

1080p Lite/720p/WD1/4CIF@25 fps (P)/30 fps (N)

Note:

1080p Lite/720p is 15 fps by default

Sub-stream:

For 1080p and 720p stream access: CIF/QVGA@15 fps

Video, Video & Audio

Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.

96 Mbps

Incoming bandwidth: 8 Mbps
