HiLook 2MP ColorVu MD 2.0 Fixed Dome Network Camera IPC-D129HA(2.8mm)

Features:

• High quality imaging with 2 MP resolution
• 24/7 colorful imaging
• Support Human and Vehicle Detection
• Water and dust resistant (IP67) and vandal resistant (IK08)
• Efficient H.265+ compression technology

Technical Specifications:

Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Max. Resolution: 1920 × 1080
Min. Illumination: Color: 0.001 Lux - (F1.0, AGC ON), 0 Lux with light
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: 24/7 color imaging
Angle Adjustment: Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355°

Lens
Lens Type: Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV:

• 2.8 mm: H: 106°, V: 57°, D: 126°
• 4 mm: H: 83°, V: 44°, D: 99°
• Lens Mount: M12
• Iris Type: Fixed
• Aperture: F1.0
• Depth of Field:
• 2.8 mm: 1.5 m to
• 4 mm: 2.1 m to
• DORI:
• 2.8 mm: D: 44 m, O: 17 m, R: 8 m, I: 4 m
• 4 mm: D: 56 m, O: 22 m, R: 11 m, I: 5 m

Illuminator
Supplement Light Type: White Light
Supplement Light Range: Up to 30 m
Smart Supplement Light: Yes

Video
Main Stream:

• 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
• 60 Hz: 30 fps (1920 × 1080, 1280 × 720)

Sub-Stream:

• 50 Hz: 25 fps (640 × 480, 640 × 360)
• 60 Hz: 30 fps (640 × 480, 640 × 360)

Video Compression:

• Main stream: H.265+/H.265/H.264+/H.264
• Sub-stream: H.265/H.264/MJPEG

Video Bit Rate: 32 Kbps to 8 Mbps
H.264 Type: Baseline Profile, Main Profile, High Profile
H.265 Type: Main Profile
Bit Rate Control: CBR, VBR
Region of Interest (ROI): 1 fixed region for main stream

Network
Security: Password protection, complicated password, watermark, HTTP authentication, WSSE and digest authentication, security audit log, MAC address host authentication
Simultaneous Live View: Up to 6 channels
API: ONVIF (Profile S, Profile T), ISAPI, SDK
Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
User/Host: Up to 32 users, 3 user levels (administrator, operator, user)
Client: iVMS-4200, HiLookVision
Web Browser: Live view requires plug-in (IE 10, IE 11), local service via Chrome 57+, Firefox 52+

Wide Dynamic Range (WDR): Digital WDR
SNR: 52 dB
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance (adjustable via software or browser)
Privacy Mask: 4 programmable polygon masks

Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port

Event
Basic Event: Motion detection (supports human/vehicle), video tampering alarm, exception
Linkage: Upload to FTP, send email, notify surveillance center, trigger capture

General
Power: 12 VDC ± 25%, 0.4 A, max. 5 W; PoE: 802.3af, Class 3, 36—57 V, 0.15—0.2 A, max. 6.5 W
Material: Base: aluminum alloy, Cover: plastic
Dimension: Ø121.5 mm × 97.6 mm (Ø4.8 × 3.8")
Package Dimension: 150 × 150 × 141 mm (5.9 × 5.9 × 5.9")
Weight: Approx. 500 g (1.1 lb), with package 700 g (1.5 lb)
Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% non-condensing
Startup/Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% non-condensing
Language: English, Ukrainian

General Function: Heartbeat, anti-banding, mirror, password protection, password reset via email

Approval
EMC: FCC 47 CFR Part 15, Subpart B; CE-EMC EN 55032:2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014; RCM AS/NZS CISPR 32:2015; KC KN32:2015, KN35:2015
Safety: CB IEC 62368-1:2014+A11; CE-LVD EN 62368-1:2014/A11:2017
Environment: CE-RoHS 2011/65/EU; WEEE 2012/19/EU; Reach EC No. 1907/2006

Protection: IP67 (IEC 60529-2013), IK08 (IEC 62262:2002)
