H.265+/H.265/H.264+/H.264 video compression
Up to 60 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth
Up to 8-ch network camera inputs
Up to 4-ch 1080p decoding capability
HDMI and VGA simultaneous output
Video and Audio
IP Video Input
8-ch
Up to 6 MP resolution
Incoming Bandwidth
60 Mbps
Outgoing Bandwidth
60 Mbps
HDMI Output
1-ch, 1920 `d7 1080p/60 Hz, 1600 `d7 1200/60 Hz, 1280 `d7 1024/60 Hz, 1280 `d7 720/60 Hz
VGA Output
1-ch, 1920 `d7 1080p/60 Hz, 1600 `d7 1200/60 Hz, 1280 `d7 1024/60 Hz, 1280 `d7 720/60 Hz
Video Output Mode
HDMI/VGA simultaneous output
Decoding
Decoding Format
H.265+/H.265/ H.264+/H.264
Recording Resolution
6 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous playback
4-ch
Decoding Capability
4-ch@1080p (30 fps) or 2-ch@4 MP (30 fps) or 1-ch@6 MP (30 fps)
Stream Type
Video, Video & Audio
Network
Remote Connection
16
Network Protocol
TCP/IP, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, UPnP`99
Network Interface
1, RJ-45 10/100Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA
1 SATA interface
Capacity
Up to 6 TB capacity for each disk
Alarm In/Out
N/A
USB Interface
Rear panel: 2 `d7 USB 2.0
General
Power Supply
12 VDC, 1.5 A
Consumption
10 W (without HDD)
Working Temperature
-10 `b0C to 55 `b0C (14 `b0F to 131 `b0F)
Working Humidity
10% to 90%
Dimension (W `d7 D `d7 H)
200 `d7 200 `d7 48 mm (7.9" `d7 8.1" `d7 1.9")
1 kg (without HDD, 2.2 lb.)
Certification
CE
EN50130-4, EN 61000-3-2,EN 61000-3-3
