4-ch (up to 12-ch)

Up to 6 MP resolution

Support H.265+/H.265/H.264+/H.264 IP cameras

8-ch

BNC interface (1.0 Vp-p, 75 ), supporting coaxitron connection

4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30

*: The 3 MP signal input is only available for channel 1/2.

1-ch, RCA (2.0 Vp-p, 1 K)

8-ch via coaxial cable

When 1080p Lite mode not enabled: 4MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF;

When 1080p Lite mode enabled: 1080p lite/720p/VGA/WD1/4CIF/CIF

Main stream:

When 1080p Lite mode not enabled:

For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30 fps (N)

For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps

For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

When 1080p Lite mode enabled:

For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p lite/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps(N)

For 3 MP stream access: 3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF@15fps

For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA/CIF@25 fps (P)/30fps (N)

For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

Sub-stream:

WD1/4CIF/2CIF@12 fps; CIF/QVGA/QCIF@25 fps (P)/30 fps (N)
