Hirose (DF40C-10DP-0.4V(51)) Mezzanine Connector, Header, 0.4 mm, 2 Rows

Mezzanine Connector, Header, 0.4 mm, 2 Rows, 10 Contacts, Surface Mount,Phosphor BronzeProduct OverviewThe DF40 series Board-to-Board and Board-to-FPC Connector with space savingdesign that has a minimum connector width, yet still retains a sufficient vacuumarea for easy pick-and-place mounting. In addition to its space saving design,several stack heights are available and add versatility to any application.Stack heights - 1.5, 2, 2.5, 3, 3.5 and 4mm. Despite its small stature and lowprofile, the contacts deliver strong contact forces and an effective matinglength of 0.45mm on the 1.5mm stacking height. This connector utilizes a lockingsystem that prevents accidental unmating issues and emits a clear tactile clickto ensure that mating has been completed. The use of guide ribs allows 0.33mm ofself-alignment on this connector. Both sides of the connector have beenreinforced with the addition of shock absorbing ribs. Nickel-plated barrierswere added to protect the contact areas from potential solder wicking.High density mountingMultiple stack height optionsHigh contact reliabilityReinforced structure with shock absorbing ribsSolder wicking preventionContamination resistant designHigh speed signal with noise preventionMinimum Width: 3.38mmApplicationsIndustrialProduct InformationMezzanine Connector Type: HeaderNo. of Contacts: 10ContactsPitch Spacing: 0.4mmNo. of Rows: 2RowsConnector Mounting: Surface MountContact Material: Phosphor BronzeContact Plating: Gold Plated ContactsProduct Range: DF40
