| Sound Enhancement |
|
| Sound Mode | Balance, Classic, EQ Volume, Extra Bass, Funk, Jazz, Natural, Pop, Rock, Samba, Standard |
| Mechanical Features |
|
| Material Body | Wooden Box |
| Net Grill | Metal Grill |
| Take Way | Hand Take |
| Sound Features |
|
| Sound Mode | Balance, Classic, EQ Volume, Extra Bass, Funk, Jazz, Natural, Pop, Rock, Samba, Standard |
| Drivers |
|
| Drivers: Speaker net | Metal Grill |
| L/R tweeter: Box type | Bass Port |
| L/R Tweeter Bar Freq Response | 2KHz-20kHz |
| L/R Tweeter Speaker Unit Tweeter | 2 x 2 |
| Woofer: Box type | Bass Port |
| Woofer: Box volume | 16.06L x 2 |
| Woofer: Bar Freq Response | 50Hz-5kHz |
| Woofer: Speaker unit | 6.5 x 2 |
| Terminals |
|
| Input | Guitar Input (Pin Jack / 6.35), Line In (Pin Jack / 3.5), Mic Input (Pin Jack / 6.35), USB Port for Service & Playback |
| Output | RCA for Party chain (Back), USB (0.5A+2.1A charge) |
| Functions |
|
| Keys | Guitar Volume, Lighting, Master Volume, Mic echo, Mic Volume |
| Key | Tact Key |
| Decoder Function | AAC, Dolby Digital, Dolby Virtual Speaker, DTS Digital Surround, MP3 (Sampling Freq: 32kHZ to 48kHZ. Bit Rate: 32 to 320kbps), PCM (2ch), WMA (Sampling Freq: 32kHZ to 48kHZ. Bit Rate: 40 to 192kbps) |
| HDMI Function | 4K Pass through (24p) |
| Bluetooth Connectivity | 6 Multi-Pairing |
| Party Chain | Wired Party Chain |
| Lighting Mode | Breath, Flashing, Racing |
| Smartphone app | Android, APP. (Panasonic Music Streaming) iOS, NFC Control (Android) |
| Software Upgrade | SW upgrade from USB Flash Drive |
| Eco | Auto Power Down (15 minutes to Standby when no source trigger) |
| Display |
|
| Display Method | Dimmer: Yes, LED |
| Characters | 4 character |
| Display Colour | White |
| Amplifier |
|
| Amp Dimensions W x H x D | 317 x 818 x 439mm |
| Amp Type | 2.0CH |
| Output Power (RMS (10% THD), PMPO) | 4 x 50W, THD: 10% |
| Power Supply |
|
| Voltage | 100-240AV |
| Frequency | 50-60Hz |
| Power Consumption in Standby Condition Target | 0.5W |
| Audio Accessories |
|
| O/I | Adding Special Language Default EN, Additional Paper Guide: Quick Setting Guide, Language Default EN |
| Warranty Card | Yes |
| Other Accessories | AC Adaptor, AC Cord, AC Plug Adaptor (PU / PX model) |
| User Interface |
|
| Display Colour | White |
| Key | Tact Key |
| Radio Tuner |
|
| FM | FM (Stereo / Monaural) |
| FM Tuning Range (50kHz / 100kHZ) | 87.5 108.0 MHz |
| Standard Spec | Tuner Area |
| Operation/Function | Auto Tuning |
| Connectivity |
|
| Input | Guitar Input (Pin Jack / 6.35), Line In (Pin Jack / 3.5), Mic Input (Pin Jack / 6.35), USB Port for Service & Playback |
| Output | RCA for Party chain (Back), USB (0.5A+2.1A charge) |
| Features |
|
| Smartphone app | Android, APP. (Panasonic Music Streaming) iOS, NFC Control (Android) |
