Name: HK Audio LINEAR 9 210 LTA
SKU: LINEAR 9 210 LTA
Price: 76795.00 ZAR
Availability: InStock

HK Audio LINEAR 9 210 LTA

New

4 available

Indicative market price: R83,995.00

Only 4 left – grab it before it’s gone!

R76,795.00

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller allows collection for this item. Buyers will receive the collection address and time once the order is ready.

The seller has indicated that they will usually have this item ready to ship within 3 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

Soundselect659

98.10 % Positive ratings

Buyer protection

How you're covered

Condition

New

Location

South Africa

Product code

LINEAR 9 210 LTA

Bob Shop ID

652483931

Features

Constant-curvature, point-source speaker for clusters and standalone use cases
60° x 25° Multicell Transformer, rotatable by 90°
2 x 10 bass/ midrange speaker
4 premium HF driver with a 2.5 voice coil
72 dB FIR-crossover, 1.35 kHz cutoff
DSP controller on board for remote management and network connectivity
DSP Out to connect conventional speakers to the network
Windows und macOS DSP CONTROL software
Overall output power: 1000 watts peak (Class-D, biamped)
Frequency response: +/- 3 dB: 88 Hz — 19 kHz
142 dB max. SPL peak (half-space)
PowerCon mains port and PowerCon Link power outlet
PU-coated birch-multiplex enclosure
Factory presets for typical use cases plus user-programmable presets
Made in Germany

Specifications

" data-order=" ">	" data-order=" ">
Max. SPL @ 10% THD	133 dB half space* (88 Hz — 12 kHz averaged)
Max. SPL peak @ 10 % THD	142 dB half space*
Frequency response +/-3 dB	88 Hz — 19 kHz*
Frequency response -10 dB	82 Hz 20 kHz*
Power amp output (RMS)	1,000 W
Amp type	Class D — Biamped
LF driver	—
Low-/mid speaker	2x 10, 2.5 voice coil
HF driver	1.4, 2.5 voice coil
Horn directivity	60° x 25° MCT horn, rotatable
Active crossover frequency	1.35 kHz FIR X-over with 72 db/oct.
Maximum input level	+20 dBu
Analog inputs	1x XLR combo balanced
Analog thru	1x XLR balanced
DSP Out	1x XLR
Network port	Ethercon RJ45, 1x In, 1x Thru
Filter presets	Stand Alone, Cluster (2), Cluster (3), Remote
Remote software	DSP CONTROL (Windows, macOS)
DSP functions	Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
Sample rate	96 kHz
System latency	Less than 2.9 ms
Mains connector	1x Powercon NAC3 In, 1x Powercon NAC3 Thru, 100—240 V
Power consuption	2.5 A / 100—240 V nominal according to EN 62368-1
Clustering angle	25°
Angles up (Monitor angle)	—
Pole mount	DuoTilt 3°/7°
Rigging points	—
Carrying handles	2x MultiGrip
Housing	Birch multiplex
Finish	PU coating black
Front grille	2 mm metal grille backed with black acoustic foam
Dimensions (WxHxD)	34 cm x 96 cm x 39 cm
Weight	33 kg / 72.8 lbs
