Product information
JG540A Specification
JG540A Specifications
Type
HPE OfficeConnect 1910 48 Switch
Ports
· 48 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX)
Duplex: half or full 2 SFP 100/1000 Mbps slots (IEEE 802.3u Type 100BASE-FX, IEEE 802.3z Type 1000BASE-X)
· 2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
Duplex: 10BASE-T/100BASE-TX: half or full
1000BASE-T: full only
· 1 RJ-45 console port to access limited CLI port
· Supports a maximum of 48 autosensing 10/100 ports plus 2 autosensing 10/100/1000 ports plus 2 SFP 100/1000 slots
Memory and processor Module
MIPS @ 500 MHz, 32 MB flash, 128 MB RAM; packet buffer size: 1.5 MB
Management
IMC - Intelligent Management Center
limited command-line interface
Web browser
SNMP Manager
IEEE 802.3 Ethernet MIB
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)
100Mb Latency
< 5 μs
1000Mb Latency
< 5 μs
Throughput
up to 13.1 Mp/s (64-byte packets)
Routing/Switching capacity
17.6 Gb/s
Routing table size
32 entries (IPv4)
32 entries (IPv6)
MAC address table size
8192 entries
Dimensions (H x W x D)
4.4 x 44 x 17.3 cm (1.73 x 17.32 x 6.81 in)
Weight
2.3 kg (5.07 lb)
Voltage
100-240 V ac
Frequency
50/60 Hz
Maximum power rating
22 W
Operating temperature
0° to 40°C (32° to 104°F)
Operating relative humidity
10% to 90%, non-condensing
Non-operating/Storage temperature
-40° to 70°C (-40° to 158°F)
Non-operating/Storage relative humidity
10% to 95%, noncondensing
Safety
IEC 60950-1
EN 60950-1
UL 60950-1 2nd Edition
CSA C22.2 No. 60950-1-07 2nd Edition
Emissions
FCC part 15 Class A
VCCI Class A
EN 55022 Class A
CISPR 22 Class A
EN 55024
EN 61000-3-2 2000
61000-3-3
ICES-003 Class A
Device management
RFC 2819 RMON
General protocols
IEEE 802.1D MAC Bridges
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s (MSTP)
IEEE 802.1w Rapid Reconfiguration of Spanning Tree
IEEE 802.3 Type 10BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
IEEE 802.3i 10BASE-T
IEEE 802.3x Flow Control
IEEE 802.3z 1000BASE-X
MIBs
RFC 1213 MIB II
RFC 1493 Bridge MIB
RFC 2021 RMONv2 MIB
RFC 2233 Interface MIB
RFC 2571 SNMP Framework MIB
RFC 2572 SNMP-MPD MIB
RFC 2573 SNMP-Notification MIB
RFC 2573 SNMP-Target MIB
RFC 2613 SMON MIB
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting MIB
RFC 2665 Ethernet-Like-MIB
RFC 2667 IP Tunnel MIB
RFC 2668 802.3 MAU MIB
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2737 Entity MIB (Version 2)
RFC 3414 SNMP-User based-SM MIB
RFC 3415 SNMP-View based-ACM MIB
RFC 3418 MIB for SNMPv3
Network management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
IEEE 802.1D (STP)
QoS/CoS
IEEE 802.1P (CoS)
Security
IEEE 802.1X Port Based Network Access Control
