Specifications:
Form Factor
Size: 219*138*35mm
Features
LTE Cat7 DL/UL 2CC
FDD-LTE: 300Mbps(DL), 100Mbps(UL)
TDD-LTE: 220Mbps(DL), 20Mbps(UL)
Band
LTE: B1/3/8/20/28/38/40/41 (B41 full band 2496~2690MHz) UMTS: B1/8 No GSM
UL: 3C/38C/40C/41C
DL: 3C/38C/40C/41C/38A-38A/41A-41A/1A-3A/1A-8A/1A-20A/1A-28A/3A-8A/3A-20A/3A-28A/3A-38A/3A-41A/8A-41A/28A-40A
Interface
4xRJ-45 for data, GE(1 LAN/WAN+3 LAN)
1xRJ11 for voice, Voice: CS&VoIP&VoLTE, VoLTE need to customized
2xSMA external antenna interface for LTE
1xSIM card slot (3FF), 1x power interface
1*Hi(WPS) KEY/1*Reset KEY/1*Power KEY
WiFi
802.11 b/g/n 2*2 MIMO 2.4GHz & 802.11a/n/ac 2*2 MIMO 5GHz
2.4GHz &5GHz DBDC
Power
AC/DCAC: 100 V ~ 240 V; DC: 12 V, 1 A
