Dimensions:181 × 126 × 36 mm (Packaging dimensions: 220 x 185 x 55 mm)
Weight:350 g
Contents of box
1 x Wireless Gateway
1 x Power supply adapter
1 x Ethernet cable
Hardware Specifications:
Technical standard:
- WAN : 3GPP Release 9
- LAN : IEEE 802.3/802.3u
- WLAN : IEEE 802.11b/g/n
Working band/frequency:
- LTE : B1/B3/B7/B8/B20
- UMTS : B1/B8
- GSM : B2/B3/B5/B8
- WLAN : 2.402 GHz?2.482 GHz
Antennas:
- Built-in LTE/UMTS/GSM primary antenna
- Built-in LTE/UMTS secondary antenna
1 x Quick Start
- One power adapter port
- One LAN/WAN port (RJ45), IEEE 802.3/802.3u
- One external LTE antenna ports (SMA)
- One SIM card slot (Mini-SIM)
- Built-in WLAN 2.4 GHz antenna
Ports:
Power Consumption: < 12 W
AC/DC power supply:
- AC (input): 100V-240V 50Hz/60Hz
- DC (output): 12V/1A
System requirements:
Operating system
- Windows 7
- Windows 8
- Windows 8.1
- Windows 10
- MAC OS X 10.9, 10.10, 10.11 and 10.12 with latest updates
Web browser:
- Microsoft Internet Explorer 8.0 with latest updates.
- FireFox 49.0 with latest updates.
- All major versions of Chrome in the last year (53.0 with latest updates).
- Safari 10.0 with latest updates (MACOS).
