Huawei AC1200 Wi-Fi Fibre router Up to 32 Wi-Fi users 4 antennas GE ports/ DUAL Band.

Huawei AC1200 Wi-Fi router. Up to 32 Wi-Fi users. 4 antennas. GE ports; DUAL Band.

Product Code WS5200

EAN Code 6901443356676

ICASA TA-2019/5327

WS5200 brings 2.4GHz and 5GHz signal together, and it will automatically connect the users devices to the faster frequency according to the devices location.

WS5200 with full GE ports design can meet the access requirements for 100+Mbps broadband users.

Features

Dual-core 800MKz CPU for High Performance

Four 5dBi High Performance Antennas for Better Coverage

Wi-Fi AC1200 Dual-band Auto-selection

Gigabit Ethernet Ports

HUAWEI Smartphone APP

Functions

Automatically identifying Internet access mode

The router can automatically identify your Internet access mode (PPPoE/DHCP). No manual

operation is required.

NOTE

PPPoE, DHCP, static IP, and bridge are the most commonly used Internet access modes and are all

supported by HUAWEI WiFi WS5200.

Learning the Internet settings of old routers

Supports obtaining the broadband account and password from your old router without

manual input. Especially when you forget your broadband account or password, you can

copy them from your old router to access the Internet.

Supports the cloning of your old router's MAC address. When broadband is enabled,

some service providers will bind your broadband account to a MAC address to limit the

number of Internet devices, and only allow bound devices to access the Internet. To

resolve this issue, the MAC address cloning feature allows the router to use the MAC

address of a bound device to access the Internet.

Multi-router network distribution

Supports network expansion by connecting multiple HUAWEI HiLink routers using the

HiLink button.

Supports network expansion by connecting multiple HUAWEI HiLink routers using

Ethernet cables.

Supports the auto-sync of your router's Wi-Fi configurations: If the Wi-Fi name,

password, or router management password is changed on your primary router, the

configuration will automatically sync to the others HUAWEI HiLink routers.

If there are multiple routers in your home, your Wi-Fi device will be automatically

switched to a better-performing router.

Connecting to your old router (through wired bridge or wireless repeater mode) to form a network

You can use an Ethernet cable to cascade HUAWEI WiFi WS5200 to an old router and

form a network. In this case, HUAWEI WiFi WS5200 works as the secondary router.

HUAWEI WiFi WS5200 can also connect to your old router's Wi-Fi as a wireless

repeater. When it functions as a wireless repeater, it has the same Wi-Fi name and

password as your old router. There will be only one Wi-Fi network in your home.

NOTE

If you have two HUAWEI routers that support HUAWEI HiLink, using HUAWEI HiLink to connect the

two routers will be more convenient.

Ensuring privacy with multiple security mechanisms

HUAWEI WiFi WS5200 controls Wi-Fi access and disconnects unwanted devices to

prevent unauthorized access.

It supports guest Wi-Fi. You can set up a dedicated Wi-Fi network for your guests.

Guests have access to the guest Wi-Fi but cannot manage the router or access other

devices on the home network. This allows you to protect the security and privacy of your

home network.

You can hide your Wi-Fi name to improve network security. If a Wi-Fi name is hidden,

wireless devices (like PCs and mobile phones) cannot search for the Wi-Fi name. To

connect a wireless device to a hidden Wi-Fi network, you must enter the correct Wi-Fi

name.

The built-in firewall can protect you from DoS/ARP attacks by scanning all data

communication between the Internet and your home network.

It supports DMZ feature that allows you to expose the DMZ host to the Internet, while

other devices are protected by the firewall. For example, when setting up a server, you

can set the computer connected to the external network as the DMZ host to allow it to

provide Internet services while ensuring the security of other devices on your home

network.

Power-saving features

The router supports three different power modes: Wall (highest power consumption),

Standard, and Sleep (lowest power consumption) to cater to your different needs at

different time of the day and in different environments.

Wi-Fi timer allows you to disable Wi-Fi during specific time periods (such as after

midnight or when you're at work) in order to reduce power consumption.

Parental control

The parental control feature allows you to set Internet access time limits and restrict access to

certain websites to keep your family members (especially minors) protected.

Router management

You can access your router's web--based management page from your computer, mobile phone based management page from your computer, mobile phone or tablet. Alternatively, you can download and install or tablet. Alternatively, you can download and install HUAWEI SmartHome app on your mobile phone or tablet for faster configuration.

Supporting VPN passthrough

Supports VPN passthrough (requires VPN dialing from LAN device).

Other supported features

NAT and NAPT (RFC 1631, RFC 2663, RFC 2766, and RFC 3022)

Supports access to the Ipv6 network.

DHCP server and clients

DNS proxy

Proxy for DNS queries from its connected devices to speed up speed up DNS responses.

DDNS proxy

The router will associate its dynamic WAN IP to a fixed domain name. This allows you to use a fixed domain name to access the router's services over the Internet instead of having to manually check the WAN IP address of the router each time.

Universal Plug and Play (UPnP)

Computers in the LAN can request the router to automatically switch the port. This allows computers connected to the Internet to access the resources on any LAN computers when needed, allowing you to enjoy a more stable network while playing computer games or using apps to download files.

Specifications

Colour

White

Chipsets

CPU: Hi5651H, Dual-core 800Mprocessor

2.4 G Wi-Fi chip: Hi1151?2x2 Wi-Fi 2.4GHz?

5G Wi-Fi chip: Hi1151?2x2 Wi-Fi 5GHz 11ac?

RAM and Flash Memory

RAM:
