The Huawei S5700-28C-HI is a high-performance Layer 3 Ethernet switch designed for enterprise core, aggregation, and advanced access scenarios. Featuring 24 x 10/100/1000Base-T Ethernet ports and an expandable front card slot supporting up to 4 x 10GE or GE SFP ports, this switch delivers powerful routing, advanced security, and full-service Layer 3 capabilities.
Ideal for use in campus networks, data centers, and enterprise aggregation points, the S5700-28C-HI supports intelligent stacking (iStack), flexible modular power options, and robust environmental tolerance. It runs on Huawei's VRP software and is compatible with extensive Layer 2/3 protocols including RIP, OSPF, and multicast.
Key Features & Benefits
24 x 10/100/1000 Mbps RJ45 Ports full Gigabit access for end-user devices
1 x Front Card Slot supports 2 or 4-port 10GE/GE SFP+ expansion modules
Dual Hot-Swappable Power Slots supports AC and DC redundancy (1+1)
Full Layer 3 Switching includes RIP, OSPF, static routing, and multicast support
USB and Console Ports supports file transfer, software upgrades, and CLI access
ETH Management Port remote and local configuration without service interruption
iStack Support scalable stacking via front 10GE uplinks (from V200R003C00 onward)
Industrial-Grade Durability operates from -5°C to +55°C with surge protection
EMI & Safety Certified meets enterprise-grade compliance standards
Ideal Uses
Enterprise core or aggregation switch in large Layer 3 networks
Campus or building backbone with high availability requirements
Industrial or power utility networks requiring rugged Layer 3 switching
Advanced security and routing applications in high-density deployments
Specifications
Condition: device with no signs of previous use. Device has been extensively tested and is 100% functional.
Brand: Huawei
Model: S5700-28C-HI
Part Number: 02353630
Ports:
24 × 10/100/1000Base-T Ethernet ports
1 × Front Card Slot (supports 2 or 4-port 10GE/GE SFP modules)
1 × Console Port (RJ45)
1 × ETH Management Port
1 × USB 2.0 Port
Power Supply Slots: 2 × Hot-swappable (AC/DC compatible)
PoE Support: Not supported
Memory: 512MB RAM, 64MB Flash
Switching Capacity: Based on front card configuration
Stacking Support: Yes (from version V200R003C00 and above using front 10GE uplinks)
Management Features: SNMP, RMON, CLI, Web, Huawei eSight
Operating System: Huawei VRP
Power Consumption: Max 76.6W
Rated Voltage:
AC: 100240V AC, 50/60Hz
DC: -48V to -60V DC
Operating Temperature: -5°C to +55°C
Storage Temperature: -40°C to +70°C
Relative Humidity: 5%95% (non-condensing)
Altitude:
AC-powered: 05000m
DC-powered: 02000m
EMC & Safety: Fully certified
Dimensions (H × W × D): 44.4 mm × 442.0 mm × 220.0 mm
Weight:
Empty: 5.0 kg
Fully loaded: 6.5 kg
Warranty: 12 Month Carry-in Warranty
What's in the Box: Huawei S5700-28C-HI Switch with 1 interface slot without power module
