Huawei S5720-28X-PWR-LI-AC PoE Switch

The S5720-LI is a next-generation energy-saving gigabit Ethernet switch that provides flexible GE access ports and 10GE uplink ports. Building on next-generation, high-performance hardware and the Huawei Versatile Routing Platform (VRP), the S5720-LI supports intelligent stack (iStack), flexible Ethernet networking, and diversified security control. It provides customers with a green, easy-to-manage, easy-to-expand, and cost-effective gigabit to the desktop solution.

• Huawei S5720-28X-PWR-LI-AC switch with 24-ports 1000BASE-T, 4-ports 10GE SFP+
• Fixed port - 24 Ethernet 10/100/1000 ports, 4 10 Gig SFP+ ports

• Forwarding performance - 108 Mpps
• No extension slots
• Forwarding perfomance: 108Mpps
• Switching capacity: 336Gbps
• 16K MAC address entries
• POE switch
• Memory (RAM) -512 MB
• Flash -240 MB
• Mean time between failures (MTBF) -41 years
• Mean time to repair (MTTR) -2 hours
• Availability > 0.99999
• Service port surge protection -Common mode: ±7 kV
• Power supply surge protection ±6 kV in differential mode, ±6 kV in common mode

Stack ports  - Twenty-four 10/100/1000BASE-T ports and four 10G SFP+ ports

PoE - Supported

Rated voltage range - 100 V AC to 240 V AC, 50/60 Hz

Maximum voltage range - 90 V AC to 264 V AC, 47 Hz to 63 Hz

Maximum power consumption (100% throughput, full speed of fans)

Without PoE: 42.7 W100% PoE loads: 448.5 W (system power consumption: 78.9 W, PoE: 369.6 W)

Typical power consumption (30% of traffic load)

Tested according to ATIS standardEEE enabledNo PoE power consumption - 29.5 W
